Page 351

C0286CONNECTOR DETAILS
FREELANDER 02MY
C028 6
Description:Header
Location:Behind centre of fascia
Colour:BLUE
Gender:Female
P6830
C0292C0286
C0075
C0787
C0652
CavColCct
1ROALL
2ROALL
2RB5
3RO4
3RB5
4RO46
5WRALL
6WR8
8NK16
9NK26
10 NK ALL
11 GN ALL
12 GN ALL
13 GN ALL
17 GP ALL
18 GP 8
19 GP 8
20 GP ALL

Page 352

CONNECTOR DETAILSC0290
FREELANDER 02MY
C0 290
Description:Header
Location:Behind centre console
Colour:BLUE
Gender:Female
P6826
C0550
C0420C1023
C0417
C0294
C0290
C0153
CavColCct
1ROALL
2ROALL
3ROALL
4RO3
5RO41
6RO41
7RO3
8ROALL
9SG3
10 SG 3
11 SG 3
13 RO ALL
14 RO ALL
15 RO 47
16 RO ALL
17 RO ALL
18 RO ALL
19 RO ALL
20 RO ALL

Page 353

C0292CONNECTOR DETAILS
FREELANDER 02MY
C029 2
Description:Header
Location:Behind centre of fascia
Colour:BLUE
Gender:Female
P6830
C0292C0286
C0075
C0787
C0652
CavColCct
1KALL
2KALL
3KALL
4K6
5KALL
6KALL
7KALL
8K16
9NG16
10 NG ALL
11 NG ALL
12 NG 16
13 W ALL
14 W 8
15 W ALL
16 W 16
17 W ALL
18 W ALL
19 W ALL
20 W ALL

Page 354

CONNECTOR DETAILSC0294
FREELANDER 02MY
C0 294
Description:Header
Location:Behind centre console
Colour:BLUE
Gender:Female
P6826
C0550
C0420C1023
C0417
C0294
C0290
C0153
CavColCct
1BALL
2BALL
3B30
4BALL
5BALL
6BALL
7BALL
8B41
9B41
10 B 41
11 B 41
12 B 41
13 B 3
14 B ALL
15 B 47
16 B 3
17 B 16
18 B ALL
19 B ALL
20 B ALL

Page 355

C0294CONNECTOR DETAILS
FREELANDER 02MY
C029 4
Description:Header - NAS
Location:Inside E-box
Colour:GREY
Gender:Female
CavColCct
2YGALL
4YGALL
5YGALL
6YGALL
7YGALL
8YGALL
9YGALL
10 YG ALL
11 YG ALL
13 NK ALL
14 NK ALL
15 NK ALL
16 NK ALL
17 NK ALL
18 NK ALL
19 NK ALL

Page 356

CONNECTOR DETAILSC0296
FREELANDER 02MY
C0 296
Description:Header
Location:Behind RH side of fascia
Colour:BLUE
Gender:Female
P6831
C0296
CavColCct
5YN26
6YNALL
7YB26
12 YN 26
13 YB ALL
14 YB 26

Page 357

C0304CONNECTOR DETAILS
FREELANDER 02MY
C030 4
Description:Motor-Window-Rear
Location:Behind rear door trim panel
Colour:BLACK
Gender:Female
P6591
C0442
C0732
C0304
CavColCct
1RALL
2UALL

Page 358

CONNECTOR DETAILSC0308
FREELANDER 02MY
C0 308
Description:Speaker-Rear-RH - 3 Door
Location:Behind RH rear speaker
Colour:BLACK
Gender:Female
P6540
C0308
CavColCct
1UB2
2UK2

Page 359

C0310CONNECTOR DETAILS
FREELANDER 02MY
C031 0
Description:Speaker-Rear-LH - 3 Door
Location:Behind LH rear speaker
Colour:BLACK
Gender:Female
P6532
C0310
CavColCct
1SK2
2SB2

Page 360

CONNECTOR DETAILSC0319
FREELANDER 02MY
C0 319
Description:Mirror-Door - 3 Door
Location:Behind front door trim panel
Colour:BLACK
Gender:Female
P6568
C0319
C0531
C0530
CavColCct
1BPALL
2SWALL
3NGALL
4BALL
5BNALL
