261
12. Using the Wi-Fi function
1Connect to a smartphone.  (P255)
2Operate the smartphone.
1Connect to a smartphone. (P255)
2Operate the smartphone.
•
The function can be assigned to the top, bottom,
left or right according to your preference.
•You cannot save pictures taken in RAW format,
motion pictures recorded with [AVCHD] or with
their picture quality size set to [MP4] in 4K.
Playing back images in the camera
1 Select [ ].
•You can switch the images to be
displayed by selecting the icon ( A
)...

12. Using the Wi-Fi function
262
A Wi-Fi connection using NFC function is possible by touching the smartphone to this unit,
and you can easily transfer images displayed on the screen.
An image can be sent on site immediately after  taking it, so you can easily send it to the
smartphone
¢ of your family or friend.¢ Installing the “ Image App ” is required for use.
1Play back the picture in the camera.2Launch “ Image App ” on the smartphone.
3While  [ ]  is displayed on the connection
screen of the “...

263
12. Using the Wi-Fi function
1Connect to a smartphone.  (P255)
2Operate the smartphone.
•
The function can be assigned to the top, bottom,
left or right according to your preference.
You can send location information acquired with a smartphone to the camera. After
sending the information, you can also write it on images stored in the camera.
1 Start recording location information
2 Start recording images
3 Finish recording the location information
4 Sending and writing location information
•...

12. Using the Wi-Fi function
264
∫Start recording location information
Operate the smartphone.
∫ Finish recording the location information
Operate the smartphone.
∫ Sending and writing location information
1Connect to a smartphone.  (P255)2Operate the smartphone.
•
Cautions for Use:
Be sure to pay special attention to the privacy, the likeness rights, etc. of the subject
when you use this function. Use at your own risk.
•On the smartphone, you can set the acquisition interval of location information and...

265
12. Using the Wi-Fi function
∫Methods for sending and images that can be sent
¢ Excluding motion pictures recorded with their size set to [4K] in [Rec Quality]•Some images may not be played back or sent depending on the device.
•For information on the playback of images, check the operating instructions of the destination
device.
•For details on how to send images, refer to  P294.
Click the followings to jump to the beginning of each menu.
Sending images to a smartphone/tablet by controlling the...

12. Using the Wi-Fi function
266
1Select the menu.
2Select [Via Network] or [Direct], and connect. (P288)
3Select a device you want to connect.
•When the connection is complete, the screen is displayed. To change the send setting,
press [DISP.].  (P296)
4Take pictures.
•The pictures are sent automatically after taking them.
•To change the setting or disconnect, press [Wi-Fi].  (P252)
You cannot change the settings while sending pictures. Wait until sending is complete.
Sending an image each time a...

267
12. Using the Wi-Fi function
1Select the menu.
2Select [Via Network] or [Direct], and connect. (P288)
3Select a device you want to connect.
•When the connection is complete, the screen is displayed. To change the send setting,
press [DISP.].  (P296)
4Select [Single Select] or [Multi Select].
•To change the setting or disconnect, press [Wi-Fi].  (P252)
Sending selected images ([Send Images Stored in the Camera])
>[New Connection]  > [Send Images Stored in the Camera]  >
[Smartphone]
On your...

12. Using the Wi-Fi function
268
Displaying pictures on a TV
1Select the menu.
2Select [Via Network] or [Direct], and connect. (P288)
3Select a device you want to connect.
•When the connection is established, the screen is displayed.
4Take or play back pictures on this unit.
•To change the setting or disconnect, press [Wi-Fi].  (P252)
•When a TV is connected to this unit, the TV screen may temporarily return to the status before
the connection. Pictures are displayed again when you take or play back...

269
12. Using the Wi-Fi function
Printing Wirelessly
∫Methods for sending and images that can be sent
•
Some images may not be sent depending on the device.•For details on how to send images, refer to  P294.
1Select the menu.
2Select [Via Network] or [Direct], and connect. (P288)3Select a printer you want to connect.4Select pictures, and then print.
•The procedure for selecting pictures is the same as the one for when the USB connection
cable is connected.
For details, refer to  P315.
•To change the...

12. Using the Wi-Fi function
270
When sending images to AV device
You can send pictures and motion pictures  to AV devices in your house (home AV
devices).
∫ Methods for sending and images that can be sent
•
Some images may not be played back or sent depending on the device.•For information on the playback of images, check the operating instructions of the destination
device.
•For details on how to send images, refer to  P294.
A
Wireless access point BHome AV device
JPEGRAWMP4AVCHD
Sending an image...
