Stiga Lawn Mower PARK 4WD PRO Svan Instruction Manual

51
DEUTSCHDE
4.  Papierfilter folgendermaßen reinigen: Filter
leicht gegen eine ebene Fläche klopfen. Wenn
der Papierfilter sehr schmutzig ist, sollte er
ausgewechselt werden.
5.  Den Luftfilter in umgekehrter Reihenfolge
wieder zusammensetzen.
Zur Reinigung des Papierfilters dürfen keine
Lösungsmittel wie z. B. Petroleum verwendet
werden. Diese Lösungsmittel zerstören den
Filter.
Zur Reinigung des Papierfilters keine Druckluft
benutzen. Der Papierfilter darf nicht eingeölt
werden.
5.12...

52
ENGLISHEN
1 GENERAL
This symbol indicates WARNING. Seri-
ous personal injury and/or damage to
property may result if the instructions
are not followed carefully.
You must read these instructions for use
and the accompanying pamphlet
“SAFETY INSTRUCTIONS” careful-
ly, before starting up the machine.
1.1 SYMBOLSThe following symbols appear on the machine.
They are there to remind you of the care and atten-
tion required during use and maintenance.
This is what the symbols mean:
Warning!
Read the...

53
ENGLISHEN
NOTE! The hydraulic implement lifter must be
in floating position in order for the power take-
off to be engaged.
NOTE! The power take-off cannot be engaged
when the parking brake is activated.
2.4.2 Clutch-parking brake (1:B)
Never press the pedal while driving.
There is a risk of overheating in the
power transmission.
The pedal (1:B) has the follow-
ing three positions:
•Released. The clutch is not activated. The park-
ing brake is not activated.
•Depressed halfway. Forward drive...

54
ENGLISHEN
2.4.9 Power take-off (2:K)
Switch for engaging/disengaging the electromag-
netic power take-off for operating front-mounted
accessories. Two positions:
1. Press the front part of the switch – the
power take-off is engaged. The symbol
will light up.
2. Press the rear part of the switch – the
power take-off is disengaged.
2.4.10 Hour meter (3:P)
Indicates the number of working hours. Only
works when the engine is running.
2.4.11 Cruise control (2:N)
A switch for activating the cruise...

55
ENGLISHEN
The maximum vertical load on the towing hitch
must not exceed 100 N.
The maximum over-run load on the towing hitch
from towed accessories must not exceed 500 N.
NOTE! Before using a trailer – contact your insur-
ance company.
NOTE! This machine is not intended to be driven
on public roads.
4 STARTING AND OPERATION
The machine may not be operated un-
less the engine casing is closed and
locked. Risk of burns and crushing in-
juries.
4.1 Filling with petrolAlways use lead-free petrol. You...

56
ENGLISHEN
4.4 Start1.  Open the fuel cock. See 10.
2.  Check that the spark plug cable(s) is/are in-
stalled on the spark plug(s).
3.  Check to make sure that the power take-off is
disengaged.
4.  Do not keep your foot on the drive pedal.
5. Put the throttle control at full throttle.
Starting cold engine – pull the choke control out
fully.
Starting warm engine – the choke control
should be pressed in.
6.  Depress the clutch-brake pedal fully.
7.  Turn the ignition key and start the engine.
8...

57
ENGLISHEN
5 MAINTENANCE
5.1 Service programmeIn order to keep the machine in good condition as
regards reliability and operational safety as well as
from an environmental perspective, STIGA’s Ser-
vice programme should be followed.
The contents of this programme can be found in
the attached service log.
Basic service
 must always be carried out by an au-
thorised workshop.
First service and intermediate service
 should be
carried out by an authorised workshop, but can
also be carried out by the...

58
ENGLISHEN
5.7 Transmission, oil filterThe oil and the filter in the hydraulic power trans-
mission must be checked/adjusted or replaced at
intervals according to the table below.
Oil type: Synthetic oil 5W-50.
Oil volume at change: approx. 4.2 litres.
5.7.1 Check – adjustment
1. Place the machine on a flat surface.
2. Read off the oil level in the reservoir. See fig.
12. The level should be level with the line.
3. If necessary, top up with more oil.
5.7.2 Draining
1. Operate the machine at varying...

59
ENGLISHEN
5.9.2 Adjustment
Adjust the steering chains if required as follows:
1. Put the machine in the straight-ahead position.
2. Adjust the steering chains with the two nuts, lo-
cated under the central point. See fig. 19.
3. Adjust both nuts by the same amount until there
is no clearance.
4. Test drive the machine straight forwards and
check that the steering wheel is not off centre.
5. If the steering wheel is off centre, undo one nut
and tighten the other.
Do not over-tighten the steering...

60
ENGLISHEN
1.  Remove the protective cover of the air filter
(fig. 20).
2.  Dismantle the paper filter insert and the foam
pre-filter. Make sure that no dirt gets into the
carburettor. Clean the air filter housing.
3. Wash the pre-filter in liquid detergent and
water. Squeeze dry. Pour a little oil on the filter
and squeeze in the oil.
4.  Clean the paper filter insert as follows: Knock it
lightly against a flat surface. If the filter is very
dirty, change it.
5.  Assemble in the reverse...
