AEM AQ1 18 Flying Lead Wiring Harness 30290618 User Manual
Here you can view all the pages of manual AEM AQ1 18 Flying Lead Wiring Harness 30290618 User Manual. The AEM manuals for AQ-1 Data Logger are available online for free. You can easily download all the documents as PDF.
Page 1
WARNING: ,! This installation is not for the electronic novice or the PC illiterate! Use this system with EXTREME caution! If you are not well versed in electronics and vehicle instrumentation or are not PC literate, please do not attempt the installation. Refer the installation to an AEM trained tuning shop. A list of AEM trained tuning shops is available at http://www.aemelectronics.com/dealer_locator.php or by calling 800-423-0046. You should...
Page 2
Page 2 10-2906-18 AQ1 Harness Instructions RevA 110622.doc KIT CONTENTS 1 x AQ1 Data Logger Harness with 18” Input Leads WIRING Power Connections RED (PERM PWR)- Connect to a fused (5 Amp) constant 12 volt power source. RED (SWIGN) – Connect to a fused (5 Amp) switched 12 volt power source. BLACK (BATT GND) – Connect to a clean power ground. (Do not connect to a sensor ground) AEMnet AEMnet is an open architecture software and hardware interface based on the CAN 2.0...
Page 3
Page 3 10-2906-18 AQ1 Harness Instructions RevA 110622.doc Analog/Frequency 5-8 are analog inputs for that can optionally measure frequency (0- 5 V or 0-16 V) Examples: RPM, vehicle speed, frequency based MAF, injector duty cycle, boost control solenoid, flow sensor, hall sensor, any 3 wire pressure sensor. See “Using the AQ1 Data Logger” for more information on configuring Inputs 5-8. The corresponding wires in the harness for Analog/Frequency 5-8 are Yellow and are labeled INPUT 5, INPUT 6,...
Page 4
Page 4 10-2906-18 AQ1 Harness Instructions RevA 110622.doc switch input to start/stop Logger (Ground activated input). Figure 3 below shows wiring diagrams for an on/off activation switch and a nitrous solenoid. The corresponding wires in the harness for Digital 1-3 are Brown and are labeled SW 1, SW 2, and SW 3. SENSOR POWER The AQ1 Data Logger has an internal low current 5 volt power supply that is used for powering sensors that require a 5 volt excitation. The corresponding...
Page 5
Page 5 10-2906-18 AQ1 Harness Instructions RevA 110622.doc CAN BUS 2 Not used with AQ1 Data Logger PN 30-2500 USB The AQ1 Data Logger has two USB ports for easy connection and programming. The AQ1 Data Logger receives low voltage power from the USB port, allowing users to access the SD card and make configuration changes at all times, 12 volt power is not necessary. The black remote mount USB port in the harness is designed for easy in vehicle programming and data downloads....
Page 6
Page 6 10-2906-18 AQ1 Harness Instructions RevA 110622.doc 30-2906-18 Connector Pinout Pin Description Wire Stamping 1 Switched 12V SW IGN 2 Switch to Ground Digital Input 1 (16V Max) SW 1 3 Switch to Ground Digital Input 2 (16V Max) SW 2 4 Switch to Ground Digital Input 3 (16V Max) SW 3 5 Ground/Sheild NOT APPLICABLE 6 Permanent 12V PERM PWR 7 Sensor Ground SIG GND 8 Analog 1 (5V Max) INPUT 1 9 Analog 2 (5V Max) INPUT 2 10 Analog 3 (5V Max) INPUT 3 11 Analog 4 (5V Max)...
Page 7
Page 7 10-2906-18 AQ1 Harness Instructions RevA 110622.doc RECOMMENDED PARTS 30-51XX Analog Style Gauges 30-44XX Digital Style Gauges 30-2340 4 Channel UEGO Controller 30-4100 Digital Gauge Style UEGO Controller 30-5130 Analog Gauge Style UEGO Controller 30-2310 Inline UEGO Controller 30-2320 X-Wifi 30-2130-XX Stainless Steel Body Pressure Sensor 30-2131-XX Brass Body Pressure Sensor 30-2010 GM Style Inlet Air Temp Sensor 30-2011 GM Style Coolant Temp Sensor 30-2012 Fluid Temp...
