AltiGen comm MAXCS 88 MaxAgent Manual
Here you can view all the pages of manual AltiGen comm MAXCS 88 MaxAgent Manual. The AltiGen comm manuals for Server are available online for free. You can easily download all the documents as PDF.
Page 41
MaxAgent Manual 35 After the dialed party answers, click Yes in the dialog box. If the dialed party does not answer, click the No button. •Selecting from Menu — When a call is on hold, you can add it to the conference by right-clicking the call and selecting Join to Conference: Canceling Conference Calls You can cancel the conference using any of the following methods: •Click the No button in the conference confirmation dialog box. •Close the conference confirmation dialog box. •Click the FLASH button.
Page 42
36MaxAgent Manual •Right-click the appropriate call and select Drop From Conference. Normally, after canceling you will be reconnected automatically to the initial call. If you are not automatically reconnected and want to reconnect to the first call, click the call’s Hold Pending state cell. Note:The conference host is the user who initiates the conference call, and only the conference host can drop a call from conference. If the conference host hangs up, no one else in the conference call can...
Page 43
MaxAgent Manual 37 Using this window, you can: •Create a one-time or recurring meeting and set its parameters •Open Microsoft Outlook to send an e-mail invitation to participate in the meeting •Start and stop a meeting •Modify or delete a meeting •See meeting ID, subject, scheduler, time, frequency, start time, end time, the last time the meeting started, its status, and the resource being used. •Display or hide outdated meetings •Modify column display Working in the MeetMe Conference Window •Click a...
Page 44
38MaxAgent Manual •Use the scroll bar at the bottom of the window to display additional columns, if necessary. •Change column size by clicking and dragging a column border. •Change column order in the current window by dragging a column heading to where you want it. •You can open more than one MeetMe Conference window and work with different meetings and displays in each one. Modifications you make to the display in a MeetMe Conference window are not retained after you close the window. •You can...
Page 45
MaxAgent Manual 39 The following parameters apply to all meetings: ParameterDescription ID The conference ID is created by the system. Scheduler The name of the person scheduling the meeting. Schedule TimeThe time the Create Meeting dialog box was opened to create this meeting. Subject Identifies the subject or type of meeting. What you enter here should be easily identifiable in the meeting list. Reserved SeatsUse the Up/Down arrows or type in a number, up to 30, to indicate the number of expected...
Page 46
40MaxAgent Manual Fill in the fields of the Create Meeting dialog box, and click OK. See the following sections for directions on filling in the fields in the middle panel of this dialog box. Note:If other scheduled meetings have already reserved resources for the time period, and sufficient resources are not available for the meeting you are attempting to schedule, a message pops up telling you that there is a resource conflict. One Time Only Meeting If you select One Time Only from the Frequency...
Page 47
MaxAgent Manual 41 1. Specify the duration of the meeting, using the Up/Down arrows. 2. If the meeting is to begin as soon as it is scheduled, select Now. 3. If the meeting is to begin at another time, select On Date, and enter a date and start time. To select a date, click the Calendar button. To select a start time, click the Down arrow and use the slide bar. Weekly Meeting If you select Weekly from the Frequency drop-down list, these are your options in the middle panel:
Page 48
42MaxAgent Manual 1. In the Duration field, specify the duration of the meeting, using the Up/Down arrows. 2. In the Start field, specify the start of the meeting by clicking the Down arrow and using the slide bar. 3. In the Every field, specify how often this meeting is to occur: every week, every other week, every three weeks, and so on. 4. Check the day of the week on which this meeting will occur. 5. In the Range of Recurrence panel, use the Calendar button to select a date for the first...
Page 49
MaxAgent Manual 43 4. Select either On Date to specify a day of the month by number ( f o r e x a m p l e , t h e 1 0 t h d a y o f t h e m o n t h ) o r s e l e c t On to specify a day of the month by name (for example, the first Monday of the month). 5. If you use On Date, the specified date (for example, the 10th day of the month) may sometimes fall on a weekend day. Check the box Hold during weekend, if the meeting will be held even on a weekend day. 6. In the Range of Recurrence...
Page 50
44MaxAgent Manual Starting and Stopping a Meeting The meeting host and the MaxAdministrator (“Admin”) can start and stop a meeting. To start a meeting if you are the host, select the meeting in the MeetMe Conference window and choose Start. Once the meeting is “started,” the host can log into it (see “Joining a MeetMe Conference” on page 45). To stop a meeting before its scheduled duration is over, select the meeting and choose Stop. Manually stopping a meeting frees up resources. Otherwise, the...
