AOR AR800 Operating Manual

AR8000 operating manual
71
Each time the sequence [FUNC] [PASS] is keyed then the SELECT SCAN
status “s” is toggled so that the channel may be “tagged” (chosen / registered)
and “un-tagged” at will.
Note: If memory channels are set as “PASS” (with a lower case “p” being
displayed), the letter will be over-written by the letter “s” for SELECT SCAN.
The status of PASS has not been changed for standard SCAN mode but
SELECT SCAN “tagged” channels ignore the status of PASS.  If the channel is
“un-tagged”, the...

AR8000 operating manual
72
11-4 SELECT new “SELECT SCAN” channels using the menu
To access the “SELECT SCAN” EDIT menu place the receiver into VFO mode
then press [FUNC] [PASS].
The “SELECT SCAN” menu displays the legend “SELECT SCAN” to confirm
operation.  The left side of the second line of the LCD displays “CH-00” with
the highlight cursor flashing on the first “0”.  The “CH-00” refers to the 100
SELECT CHANNELS of the special list which are numbered 00 - 99
(examples are CH-00, CH-01, CH-03 etc).
To...

AR8000 operating manual
73
11-5 DELETE individual “SELECT SCAN” channels
To access the “SELECT SCAN” EDIT menu place the receiver into VFO mode
then press [FUNC] [PASS].
The “SELECT SCAN” menu displays the legend “SELECT SCAN” to confirm
operation.  The left side of the second line of the LCD displays “CH-00” with
the highlight cursor flashing on the first “0”.  The “CH-00” refers to the 100
SELECT CHANNELS of the special list which are numbered 00 - 99
(examples are CH-00, CH-01, CH-03 etc).
To delete...

AR8000 operating manual
74
(12)  Priority operation
The PRIORITY feature enables you to carry on scanning, searching or
monitoring while the AR8000 checks a frequency taken from one of the 1000
memory channels (A00 default) every 5 seconds (default) for activity.
The priority checking is accomplished by momentarily moving to the priority
frequency to see if it is “active”.  If activity is found, the receiver remains on the
frequency until the signal disappears.  If no activity is detected, the receiver...

AR8000 operating manual
75
To cancel priority operation press [FUNC] [4], the legend “P” will be removed
from the top line of the LCD.
12-2 Changing PRIORITY channel parameters
The default channel used for PRIORITY is “A00” and the frequency and data
copied from the channel is checked for activity every 5 seconds.
You may select a different memory channel from which the data will be copied
or may vary the sampling time for priority activity checking.  This is accom-
plished by using the “SET PRI CH” menu...

AR8000 operating manual
76
(13)  SEARCH - search banks and frequency pass
The AR8000 has a SEARCH mode whereby an upper and lower frequency
limit may be defined and the receiver instructed to look for activity on all
frequencies in predetermined step size in an upward or downward direction.
The mode and channel step will change automatically when set to the default
of AUTO-MODE but data may be specified specifically if preferred.
* It is important that you do not confuse SEARCH and SCAN modes. *
SEARCH...

AR8000 operating manual
77
Searching using the mode of WFM may not be possible in certain frequency
bands due to the level of background noise and adjacent channel activity.
13-1 Manual SEARCH between the twin VFO frequencies
The simplest form of SEARCH is achieved by programming different
frequencies into VFO “A” and VFO “B” while in 2VFO mode.
Starting manual search
To start MANUAL SEARCH press and hold [2VFO]
for more than 1 second.  The mode and step size
will always be taken from the “active” (top...

AR8000 operating manual
78
To restart the manual search process from the start
To start the manual search from the original frequency press [2VFO] to return
to 2VFO mode than press and hold [2VFO] for more than one second to
restart manual search over again.
To resume manual search from the current frequency
Once you have pressed [ENT] to place the active frequency into VFO mode,
you may resume manual search from the current frequency.  Press [FUNC]
[2VFO] to transfer the current active frequency to the...

AR8000 operating manual
79
The legend “BANK” is displayed on the left of the third line with a memory
location to the right.  Either key in the desired memory location for storage via
the keypad or use the [DIAL] (the UP/DOWN keys change the cursor position
if you make a mistake).
Press [ENT] to accept the chosen memory location.  The cursor moves to the
fourth line where a maximum seven character comment may be added.  Use
the [DIAL] and UP/DOWN keys to change the text comment as desired then
press...

AR8000 operating manual
80
13-2 Program search banks
It is possible to save parameters of frequency, mode, step step offset and
comment into any of the 20 program search banks for easy access at any
time.
The program search banks (referred to simply as search banks) are identified
by letters A, B, C, D, E, F, G, H, I, J  (upper case letters) and a, b, c, d, e, f, g,
h, i, j (lower case letters).
Remember: It is possible to set a PASSWORD to prevent unauthorised access
to banks with lower case letters (a,...
