12.  INSTALLATION OF INDOOR UNITS
12.1  PREPARATION STEPS OF INDOOR UNIT BEFORE INSTALLATION
a.  Put packed unit as shown.
  Remove plastic strap (item 1) from
cardboard.






d.  Lift insert grille to the top of the unit
with both hands and it will be
automatically separated from unit.







e.  Disassemble terminal block cover
by removing two screws from grille
frame.

b.  Slide unit from carton (item 1)
  Lift unit with Styrofoam
  Parts from carton box...



19

INSTALLATION OF INDOOR UNITS (Cont.)

12-2  INSTALLATION STEPS OF INDOOR UNIT
STEP (1): Selecting Wall Hole Location Back Piping
In case of passing refrigerant piping lines, electrical cables
and condensate drain line behind the unit, drill a hole of 8 cm
behind the unit in one of the following locations as per
sequence:
Location (A): behind unit right.
Location (B): behind unit Left.


Side or bottom piping
In case of passing refrigerant piping lines, electrical cables
and...



20

INSTALLATION OF INDOOR UNITS (Cont.)

  INSTALLATION STEPS OF INDOOR UNIT (Cont.)

NOTES:
a.  Fasten the wall hang bracket to the wall with
all the 5 (Five) screws supplied with unit.
  This correct fixation will prevent motion of
bracket after fixation, which can cause noisy
unit operation.


b.  The wall hang bracket must be leveled in both
horizontal and vertical directions after fixation
without tilting to the right or lift to avoid water
dropping from the unit onto the...



21

INSTALLATION OF INDOOR UNITS (Cont.)

INSTALLATION STEPS OF INDOOR UNIT (Cont.)
Step (8): Passing refrigerant piping,
electrical cords and drain hose
of indoor unit through wall
sleeve.

• Passing refrigerant piping lines
through the wall sleeve is done before
hooking the indoor unit body onto the
top of the wall hang bracket.

• For left piping, hang the unit onto the
top of the wall hang bracket and
incline the unit using a tool such as a
screw driver set between the middle...



22

13.   REMOTE CONTROL INSTALLATION
  13.1  HOW TO INSERT BATTERIES:
(a) Remove the cover of battery compartment at the back of the remote
control by pressing the tab toward inside, in the direction of the arrow.







(b) Mount the two-battery size AAA 1.5 Volt supplied with the remote control.
Then close the cover of the battery component.

Note:

During mounting of batteries check battery symbols (+, -) indicated in
batteries compartment.


NOTES:
1.  The remote control...



23

14.  OUTDOOR UNIT INSTALLATION

14.1   PREPARATION STEPS BEFORE INSTALLATION

a.  Put packed unit as shown.


b.  Lift unit from cardboard.









c.  Remove service door (item 2) by
removing one screw (item 1).
  Detach the cable clamp by
  removing one screw.








14.2   INSTALLATION STEPS
WALL INSTALLATION STEPS  FLOOR INSTALLATION STEPS

Wall Support Dimensions (mm)













Floor Support Dimensions. (mm)


fix wall support into...



24

15.  CONNECTING REFRIGERANT PIPING LINES
15-1   INSTRUCTIONS FOR CONNECTIING REFRIGERANT PIPING LINES

Avoid excessive height difference
between indoor and outdoor units.

Avoid excessive length of refrigerant
piping lines between indoor and outdoor
units
 - All bends must be considered when
connecting indoor unit with outdoor unit
by required length
  of refrigerant piping lines.
-  Do not remove the protective caps from
the couplings until the refrigerant piping
lines are...



25

CONNECTING REFRIGERANT PIPING LINES (Cont.)
INSTRUCTIONS FOR CONNECTIING REFRIGERANT PIPING LINES (Cont.)
 The minimum radius of bending must not
be less than 100 mm to avoid damage of
tubing.
Once the tubing is bent, the installer must
not unbend at the same point as this
causes work hardening of copper tubing
and makes it more difficult to reshape

Avoid disconnecting refrigerant
connections after they have been tightened
to avoid refrigerant leaks.
 When there is excessive...



26
L

CONNECTING REFRIGERANT PIPING LINES (Cont.)
15.2  USE OF REFRIGERANT PIPING LINES
The following data refers to the use of refrigerant piping lines of diameters equivalent to that use in
units where:           L   =  Maximum length of refrigerant piping lines between outdoor and indoor unit.
H  =  Maximum vertical distance between outdoor and indoor units.
(A) OUTDOOR UNIT BELOW INDOOR UNIT:
a.  Suction line should rise above height of Indoor unit to shape a liquid trap in an inverted...



27

CONNECTING REFRIGERANT PIPING LINES (Cont.)

15-3  LENGTHS AND DIAMETERS OF REFRIGERANT PIPING LINES FOR ALL MODELS

S L
5/8” 3/8”
S =   Suction line diameter.
L  =  Liquid line diameter.


15.4  REFRIGERANT CHARGE.

• For refrigerant piping lines of length more than 3 meters, add 25 grams of refrigerant per
extra meter from 3 meters refrigerant piping lines:

Example 1  = For 8 meter lines, refrigerant added   = (8-3)  x 25  = 125  grams.

Example 2  = For 12 meter lines,...
