1 Overview.

1.1 Introduction

The  FDM -77  is  conceived  as  a  SDR  (  Software  Defined  Radio).  This  approach  m eans  that  the
receiving set is composed of a Hardware RF front -end and a PC with an ELAD Software Radio.

The  Software  Radio  is  the  operator’s  main  interface  (GUI)  for   the  control  of  the  radio  (Input,
Tuning, Setup, Mode, Display and AF ) and is also used to decode and reproduce t he audio through
the PC soundcard.



There...

          4



The FDM -77 set includes :

·  RF front -end ( The Gray box on the right side)
·   ELAD software radio ( CD ROM)
·   Power supply ( The black box on the left side)
·   Audio cable
·   USB cable

Personal Computer is not included.


          5

1.3 Front & Rear Panel

The front panel of the Hardware RF front -end includes:

  ·   A POWER ON LED
·   A MONITOR LED  to show the communication establishe d between the Hardware RF front-end and the PC.
·   A 7 LEDs BAR to show the presence and relevant stre ngth of a signal at the input of the receiver.

The rear panel includes:

  ·   A SO 239 socket for the connection of an external a ntenna.
·   A BNC socket for the connection of an indoor antenn a.
·   A SPDPT switch...

          6

·  Connect the external antenna through a good quality RG 8 coax cable f itted with a PL 259 Plug
or  the  indoor  antenna  through  the  BNC  socket.  Best  performances  are  obtai ned  with  a  good
external  antenna.  If  an  external  antenna  is  not  available  we  recom mend  the  use  of  the  whip
antenna offered as optional, but every indoor antenna provided with a BCN plug is suitable.
·   Through the supplied shielded cable fitted with  3.5 mm stereo plugs connect  the 12...

          7

1.5 Accessories

Your FDM -77 is supplied complete of the following accessories:

·   A mini 1/8” 3.5mm stereo plug male to male cable ( L = 2m).
·   A MH USB 2.0 cable A to B (L = 1.8m)
·   A 230 V AC / 12 V DC power supply



Optional accessories:

·   Rechargeable Battery pack
·   Whip indoor antenna



          8

1.5 Controls and Functions

1.5.1 Graphical user Interface (GUI).

Main screen

The screen shot below shows the main screen (the cockpit) of the Graphical User I nterface :



In the upper left side there is a window dedicated to:
display  the  operating  frequency,  mode  (  CW,  LSB,  USB,  AM,  FM,  DRM),  VFO  (variable
frequency oscillator) , MEM and CH to select the operating frequency .

In the upper right side there is the window dedicated to :
display...

          9

2 Operation of the Receiver – Basic

2.1 Switching on/off the FDM – 77
Insert the 12V DC plug cable into the DC socket  and push on/off the switch on the rear panel of the
radio. Power on will be indicated also through the “power on”  led on the front panel. In order t o
avoid blocking of the software the following sequences must be followed.
Switching on :
1.  Connect the 12 V DC  and switch on the power on/off switch
2.  Connect the USB cable from de PC to the RF front -end....

          10

2.3 Frequency selection
There are two main modalities to choose the operating frequency: VFO and  MEMORY.

2.3.1 Selection of the operating frequency through the main shuttle knob.
Click the VFO button ( the VFO label is activated in the Frequency  window) if you want to browse
the  frequency  range  trough  the  main  shuttle  knob  as  in  a  traditional  wa y.  This  is  the  free  VFO
control.



2.3.2 Selection of the operating frequency through the memory.
Click  the...
