Epson Vs400 Users Guide

Parent
topic:Setting Upthe Projector
 31

Using
BasicProjector Features
 Follow
theinstructions inthese sections touse your projectors basicfeatures.
 Turning
Onthe Projector
 Turning
Offthe Projector
 Selecting
theLanguage forthe Projector Menus
 Adjusting
theImage Height
Shape
 Resizing
theImage WiththeZoom Ring
 Focusing
theImage UsingtheFocus Ring
 Remote
ControlOperation
 Selecting
anImage Source
 Projection
Modes
Aspect Ratio
 Color
Mode
 Turning
Onthe Projector
 Turn
onthe computer orvideo equipment youwant touse before...

2.
Connect thepower cordtothe projectors powerinlet.
 3.
Plug thepower cordintoanelectrical outlet.
 The
projectors powerlightturns orange. Thisindicates thattheprojector isreceiving power,butis
 not
yetturned on.
 Note:
WithDirect Power Onturned on,theprojector turnsonassoon asyou plug itin.
 4.
Press thepower button onthe projector orthe remote controltoturn onthe projector.
 The
projector beepsandthepower lightflashes greenasthe projector warmsup.After about five
 seconds,
thepower lightstops...

Related
references
 Projector
SetupSettings -Extended Menu
 Turning
Offthe Projector
 Before
turning offthe projector, shutdown anycomputer connected toitso you canseethecomputer
 display
duringshutdown.
 Note:
Turnoffthis product whennotinuse toprolong thelifeofthe projector. Lamplifewill vary
 depending
uponmode selected, environmental conditions,andusage. Brightness decreasesovertime.
 1.
Press thepower button onthe projector orthe remote control.
 The
projector displaysashutdown confirmation...

3.
Totransport orstore theprojector, makesurethepower lightisorange (butnotflashing), then
 unplug
thepower cord.
 Caution:
Toavoid damaging theprojector orlamp, never unplug thepower cordwhen thepower
 light
isgreen orflashing orange.
 4.
Close theprojectors lenscover.
 Parent
topic:UsingBasicProjector Features
 35

Selecting
theLanguage forthe Projector Menus
 If
you want toview theprojectors menusandmessages inanother language, youcanchange the
 Language
setting.Thedefault language settingisEnglish .
 1.
Turn onthe projector.
 2.
Press theMenu button.
 3.
Press thedown arrow button toselect theExtended menuandpress Enter.
 4.
Press thedown arrow button toselect theLanguage settingandpress Enter.
 5.
Select thelanguage youwant touse and press Enter.
 6.
Press Menu toexit themenus.
 Parent...

2.
Toadjust thefront foot,pulluponthe foot release leverandliftthe front ofthe projector.
 The
footextends fromtheprojector.
 3.
Release thelever tolock thefoot.
 If
the projected imageisunevenly rectangular, youneed toadjust theimage shape.
 Parent
topic:UsingBasicProjector Features
 Related
concepts
Shape
 Related
references
 Projector
FeatureSettings -Settings Menu
Shape
 You
canproject anevenly rectangular imagebyplacing theprojector directlyinfront ofthe center ofthe
 screen...

Related
references
 Projector
FeatureSettings -Settings Menu
 Related
tasks
 Adjusting
theImage Height
 Correcting
ImageShape WiththeKeystone Buttons
 You
canusetheprojectors keystonecorrection buttonstocorrect theshape ofan image thatis
 unevenly
rectangular onthe sides.
 1.
Turn onthe projector anddisplay animage.
 2.
Press akeystone buttononthe projectors controlpanel.
 After
correction, yourimage isslightly smaller.
 Note:
Ifthe projector isinstalled outofreach, youcanalso correct theimage shape...

2.
Toenlarge orreduce theimage size,rotate theprojectors zoomring.
 Parent
topic:UsingBasicProjector Features
 Focusing
theImage UsingtheFocus Ring
 1.
Turn onthe projector anddisplay animage.
 2.
Tosharpen theimage focus,rotatetheprojector ’s focus ring.
 Parent
topic:UsingBasicProjector Features
 39

Remote
ControlOperation
 The
remote controlletsyou control theprojector fromalmost anywhere inthe room, upto26 feet (8m)
 away.
Youcanpoint itat the screen, orthe front orback ofthe projector.
 Make
surethatyouaimtheremote controlatthe projectors receiverswithintheangles listedbelow.
 Horizontal
angles
 Vertical
angles
 1
 26
feet (8m)
 2
 45
º
 3
 30
º
 4
 15
º
 40
