Hitachi Projector CP-A222WN User Manual

51
AUDIO menu
Item Description
MIC LEVEL
Using the ▲/▼ buttons switches the input level to match that of the
microphone connected to the MIC port.
HIGH
 LOW
HIGH: for a microphone with an amplifier.
LOW:  for a microphone without an amplifier.
MIC VOLUME
Using the ◄/► buttons adjusts the volume of the microphone
connected to the MIC port.
Low
 High

52
SCREEN menu
SCREEN menu
From the SCREEN menu, items shown in the table
below can be performed.
Select an item using the ▲/▼ cursor buttons, and
press the ► cursor button or ENTER button to
execute the item. Then perform it according to the
following table.
Item Description
LANGUAGEUsing the ▲/▼/◄/► buttons switches the OSD (On Screen
Display) language.
ENGLISH
 FRANÇAIS
 DEUTSCH
  ESPAÑOL

  (shown in the LANGUAGE dialog)
Press the ENTER or INPUT button to save the language...

53
SCREEN menu
Item Description
MyScreenThis item allows you to capture an image for use as a MyScreen
image which can be used as the BLANK screen and START UP
screen. Display the image you want to capture before executing the
following procedure.
Selecting this item displays a dialog
titled “MyScreen”. It will ask you if
you start capturing an image from the
current screen.
Please wait for the target image to be displayed, and press the
ENTER or INPUT button to start registration.
To restore the...

54
SCREEN menu
Item Description
MyScreen LockUsing the ▲/▼ buttons turns on/off the MyScreen lock function.
ON
 OFF
When the ON is selected, the item MyScreen is locked. Use this
function for protecting the current MyScreen.
• This function cannot be selected when the ON is selected to the
MyScreen PASSWORD item in SECURITY menu (
83).
MESSAGEUsing the ▲/▼ buttons turns on/off the message function.
ON
 OFF
When the ON is selected, the following message function works.
“AUTO IN PROGRESS” while...

55
SCREEN menu
Item Description
SOURCE NAMEEach input port for this projector can have a name applied to it.
(1)  Use the ▲/▼ buttons on the SCREEN menu to select SOURCE
NAME and press the ► or ENTER button.
The SOURCE NAME menu will be displayed.
(2)  Use the ▲/▼ buttons on the SOURCE
NAME menu to select the port to be
named and press the ► button. The
SOURCE NAME dialog will be displayed.
Right side of the menu is blank until a
name is specified.
(3)  Select an icon you would like to assign to...

56
SCREEN menu
Item Description
SOURCE NAME
(Continued)
(6)  The current name will be displayed on
the first line. Use the ▲/▼/◄/► buttons
and the ENTER or INPUT button to
select and enter characters. To erase 1
character at one time, press the RESET
button or press the ◄ and INPUT button
at the same time. Also if you move the
cursor to DELETE or ALL CLEAR on
screen and press the ENTER or INPUT
button, 1 character or all characters will
be erased. The name can be a maximum
of 16 characters.
(7)...

57
SCREEN menu
Item Description
C.C.
(Closed Caption)The C.C. is the function that displays a
transcript or dialog of the audio portion of
a video, files or other presentation or other
relevant sounds. It is required to have NTSC
format video or 480i@60 format component
video source supporting C.C. feature to
utilize this function.
It may not work properly, depending on equipment or signal source.
In this case, please turn off the Closed Caption.
DISPLAY
Select Closed Caption DISPLAY setting from...

58
OPTION menu
OPTION menu
From the OPTION menu, items shown in the table
below can be performed.
Select an item using the ▲/▼ cursor buttons, and
press the ► cursor button or ENTER button to execute
the item, except for the items LAMP TIME and FILTER
TIME. Then perform it according to the following table.
Item Description
AUTO SEARCH
Using the ▲/▼ buttons turns on/off the automatic signal search
function.
ON
 OFF
When the ON is selected, detecting no signal automatically cycles
through input...

59
OPTION menu
Item Description
AUTO POWER
OFFUsing the ▲/▼ buttons adjusts the time to count down to
automatically turn the projector off.
Long (max. 99 minutes)
 Short (min. 0 minute = DISABLE)
When the time is set to 0, the projector is not turned off automatically.
When the time is set to 1 to 99, and when the passed time with no-
signal or an unsuitable signal reaches at the set time, the projector
lamp will be turned off.
If one of the projector's buttons or the remote control buttons
is...

60
OPTION menu
Item Description
LAMP TIMEThe lamp time is the usage time of the lamp, counted after the last
resetting. It is shown in the OPTION menu.
Pressing the RESET button on the remote control or the ► button
of the projector displays a dialog.
To reset the lamp time, select the OK using the ► button.
CANCEL
 OK
• Please reset the lamp time only when you have replaced the lamp,
for a suitable indication about the lamp.
• For the lamp replacement, see the section "Replacing the lamp"...
