HP 5500 Ei 5500 Si Switch Series Configuration Guide

 256
•  VPN
A virtual private network (VPN) is a private dat a communication network built on the public
communication infrastructure. A VPN can leverage  network layer security protocols (for instance,
IPsec) in conjunction with PKI-based encryp tion and digital signature technologies for
confidentiality.
•   Secure email
Emails require confidentiality, integrity, auth entication, and non-repudiation. PKI can address
these needs. The secure email protocol that is de veloping rapidly is...

 257
Task Remarks
Configuring an access control policy Optional.

Configuring an entity DN
A certificate is the binding of a public key and the identity information of an entity, where the identity
information is identified by an entity distinguishe d name (DN). A CA identifies a certificate applicant
uniquely by entity DN.
An entity DN is defined by these parameters:
•   Common name of the entity.
•   Country code of the entity, a standard 2-character code. For example, CN represents China and...

 258
Step Command Remarks
8.  Configure the organization
name for the entity.  organization
 org-name  Optional.
No organization is specified by
default.
9.
  Configure the unit name for
the entity.   organization-unit org-unit-name Optional.
No unit is specified by default.
10.
 Configure the state or
province for the entity.  state
state-name   Optional.
No state or province is specified by
default.


NOTE:
The Windows 2000 CA server has some restrictions on the data length of a...

 259
•  The CA name is required only when you retrieve a CA certificate. It is not used when in local
certificate request.
•   The certificate request URL does not support domain name resolution.
Configuration procedure
To configure a PKI domain:
Step Command Remarks
1.  Enter system view.
system-view N/A
2.  Create a PKI domain and
enter its view.  pki domain domain-name
 No PKI domain exists by default.
3.  Specify the trusted CA.
ca identifier  name  No trusted CA is specified by...

 260
Submitting a certificate request in auto mode
I n  a u t o  m o d e,  a n  e n t i t y  a u t o m a t i c a l l y  re q u e s t s  a  c e r t i f i c a t e  f ro m  t h e  C A  s e r ve r  i f  i t  h a s  n o  l o c a l  c e r t i fi c a t e
for an application working with PKI, and then retrieves the certificate and saves the certificate locally.
Before requesting a certificate, if the PKI domain does not have the CA certificate yet, the entity
automatically retrieves the CA certificate.
To...

 261
•  Make sure the clocks of the entity and the CA are synchronous. Otherwise, the validity period of the
certificate will be abnormal.
•   The configuration made by the  pki request-certificate domain command is not saved in the
configuration file.
Configuration procedure
To submit a certificate request in manual mode:
Step Command Remarks
1.   Enter system view.
system-view  N/A
2.  Enter PKI domain view.
pki domain domain-name  N/A
3.  Set the certificate request
mode to manual....

 262
Configuration procedure
To retrieve a certificate manually:
Step Command  Remarks
1.  Enter system view.
system-view  N/A
2.  Retrieve a certificate
manually.
• In online mode:
pki retrieval-certificate  { ca  | local  } domain
domain-name
• In offline mode:
pki  import-certificate  { ca | local  } domain
domain -name  { der  |  p12  | pem  }  [  filename
filename  ]  Use either command.

Configuring PKI certificate verification
A certificate needs to be verified before being...

 263
Step Command Remarks
6.  Return to system view.
quit  N/A
7.  Retrieve the CA certificate.  See
Retrieving a certificate
manually   N/A
8.
  Retrieve CRLs.  pki retrieval-crl domain
domain-name
  N/A
9.
  Verify the validity of a
certificate.  pki validate-certificate
 { ca | local  }
domain  domain-name   N/A

Configuring CRL-checking-disabled PKI certificate verification
To configure CRL-checking-disabled PKI certificate verification:
Step Command Remarks
1.
  Enter system view....

 264
To delete a certificate:
Step Command
1.  Enter system view.
system-view
2.  Delete certificates.
pki delete-certificate { ca | local  } domain  domain -name

Configuring an access control policy
By configuring a certificate attribute-based access co ntrol policy, you can further control access to the
server, providing additional security for the server.
To configure a certificate attribute-based access control policy:

Step Command Remarks
1.   Enter system view.
system-view  N/A...

 265
Task Command Remarks
Display information about
certificate attribute groups. display pki certificate
attribute-group
{ group-name  |
all  } [ |  { begin |  exclude |
include  } regular-expression ]   Available in any view
Display information about
certificate attribute-based access
control policies.  display pki certificate
access-control-policy { policy-name
|
all  } [ |  { begin  | exclude |
include  } regular-expression ]  Available in any view

PKI configuration examples
This...
