Miele W1712 User Manual

Electrical connection
The washing machine is supplied with a
mains cable with moulded plug for
connection to a 230V mains supply.
The voltage, rated load and plug rating
are given on the data plate. Please
ensure these match the household
mains supply.
The accesibility of the plug must be
always ensured, in order to separate
the washing machine from the mains.
All electrical work should be carried out
only by a suitably qualified and
competent person, in strict accordance
with national and local safety...

Consumption data for AS/NZ 2040.2:2005 Standard
Max. load Consumption data
Energy Water Degree of
soiling
in kWh in litres Normal
Cottons 40°C 6.5 kg 0.50 52 1 h 51 min
Note for test institutes:
Detergentmustbe dispensed via the detergent dispenser drawer.
Consumption data can vary from the nominal values given depending on water
pressure, water hardness, water inlet temperature, room temperature, type and
volume of load, fluctuations in the electricity supply and any extra options
selected.
Load...

Height 85.1 cm
Width 59.5 cm
Depth 63.4 cm
Depth with door open 107.4 cm
Weight 99 kg
Maximum floor load 1,600 Newton (approx. 160 kg)
Capacity 6.5 kg dry laundry
Voltage see data plate
Connected load see data plate
Consumption data see Consumption data
Water flow pressure minimum 100 kPa (1 bar)
Water flow pressure maximum 1,000 kPa (10 bar)
Inlet hose length 1.60 m
Drain hose length 1.50 m
Connection cable length 1.60 m
Delivery head max. 1.00 m
Drain pump length max. 5.00 m
LEDs Class 1
Test...

Programmable functions
for changing standard settings
The programmable functions are used to alter the machines electronics to suit
changing requirements.
Programmable functions can be altered at any time.

To access programmable functions
The programmable functions are
accessed via theStart/Stopbutton
and the programme selector.
Before you begin, first ensure that:
–The washing machine is switched off.
–The machine is properly closed.
APress theStart/Stopbutton and keep
it pressed in whilst carrying out steps
B-C.
BPress theI-On/0-Offbutton in.
CAs soon as...
Language!...
. . . appears in the display, release
theStart/Stopbutton.
To select a programmable function
DTurn the programme selector until
the...

Water plus
This programmable function is used
to select the water intake setting for
theWater plusextra option.
There are three different options:
Water +
(the machine is delivered with this
option selected)
The water level is increased in the wash
and rinse stages.
Extra rinse
An extra rinse is introduced.
Water + and Extra rinse
The water intake is increased in the
wash and rinse stages and an extra
rinse is carried out.
Gentle action
Activating gentle action reduces the
drum action and is suitable...

Code
A code can be used to lock the
electronics on the washing machine
to prevent it being used without your
knowledge.
When the code has been activated, you
have to enter a code after switching the
washing machine on. Otherwise the
washing machine cannot be operated.
Code ...
^Press theStart/Stopbutton.
To activate the code
Activate
^Press theStart/Stopbutton.
The display will now request that a
code is entered.
To enter the code
The code is125and cannot be altered.
O__ __
^
Turn the programme selector...

Temperature unit
You can chose for the temperature to
be displayed as°C/Celsiusor
°F/Fahrenheit.
The machine is delivered with
°C/Celsius as the default setting.
Buzzer
When the buzzer function has been
activated, an audible tone sounds at
the end of a programme or when
Rinse hold is reached.
There are two volumes:
Normal
(the machine is delivered with this
option as the default setting.)
The buzzer sounds at the end of a
programme or when Rinse hold is
reached.
Loud
The buzzer sounds at maximum volume...

Standby display
To save energy, the display goes out
after 10 minutes and the indicator
light for theStart/Stopbutton will start
flashing slowly.
There are two options:
On
Standby is activated:
–if a programme is not selected within
10 minutes of the machine being
switched on.
– after a programme has started.
– at the end of a programme.
Not in current prog.
(the machine is delivered with this
option selected)
Standby is activated:
– if a programme is not selected within
10 minutes of the machine being...

Alteration rights reserved/3208M.-Nr. 07 168 200 / 02
