Getting Started11
ENGLISH
2.2 Parent unit battery installation and power supply
A rechargeable battery pack is supplied and should be fitted, so that the parent
unit can be carried to another location without losing the link and picture from
the baby unit(s). Charge the parent unit before using it for the first time or when
the parent unit indicates that battery is low. We recommend that the unit be
charged for 15 hours prior to first use.
1.Remove the belt clip/stand if it is attached to the...

12Getting Started
2.3 Belt clip/stand on parent unit
1.The belt clip/stand attaches to the back of the parent unit and clips into the
locking slots on each side.
NOTE
It will only fit one way, as indicated by UP and the arrows on the inner side of the
clip.
2.The unit comes with the accessory fitted in the belt clip position.
3.You can convert it into the desktop position by simply pulling the back part of
the clip out slightly and then rotating it by half a turn, as shown above.
Belt clip...

Using Your Digital Video Baby Monitor13
ENGLISH
3. Using Your Digital Video Baby Monitor
Please read these instructions carefully, and be aware that this digital video baby
m o n i t o r  i s  o n l y  i n t e n d e d  a s  a n  a i d .  I t  i s not a substitute for responsible and proper
adult supervision.
3.1 Power on or off the baby unit
•  Press and hold   to power on the baby unit. The Power/Link indicator turns
on.
•  Press and hold   again to power off the baby unit. The Power/Link indicator...

14Using Your Digital Video Baby Monitor
3.5 Adjust LCD brightness of the parent unit
You can adjust the brightness of the parent unit screen from Level 1 to Level 5.
The LCD brightness is preset to Level 3.
1.Press  when the parent unit is not in use.
2.Press
- or + to scroll to  .
3.Press < or > to adjust brightness.
4.Press   to confirm your selection.
3.6 Adjust sound sensitivity of the baby unit
You can set the sound sensitivity level (Level 1 to Level 5) of the baby unit(s) from
the parent unit....

Using Your Digital Video Baby Monitor15
ENGLISH
3.9 Select camera
You can select the baby unit you want to view, or view all baby units in Scan
Mode.
If you select Scan Mode, the screen switches to display another baby unit
automatically after some time. The switching is made in a loop:   to  .
1.Press   when the parent unit is not in use.
2.Press
- or + to scroll to  .
3.Press
< or > to select the baby unit you want to view (1, 2, 3 or 4) or Scan
Mode ( ).
4.Press   to confirm your selection.
3.10...

16Using Your Digital Video Baby Monitor
When pairing is successful, the screen displays  , followed by the image from
the newly paired baby unit.
NOTE
If pairing fails, the screen displays  . Try the pairing process again. Only one
baby unit can be paired at a time.
3.12 Talk to the baby unit
You can use the TALK function of the parent unit to talk to and comfort your
baby.
To talk to the baby unit:
1.Press and hold
T when viewing a baby unit.
2.Speak towards the microphone on the parent unit....

Disposal of the Device (Environment)17
ENGLISH
4. Disposal of the Device (Environment)
At the end of the product lifecycle, you should not dispose of
this product with normal household waste. Take this product to
a collection point for the recycling of electrical and electronic
equipment. The symbol on the product, users guide and/or
box indicates this.
Some of the product materials can be re-used if you take them
to a recycling point. By reusing some parts or raw materials from used products
you...

18Cleaning
5. Cleaning
Clean your Digital Video Baby Monitor with a slightly damp cloth or with an anti-
static cloth. Never use cleaning agents or abrasive solvents.
Cleaning and care
•  Do not clean any part of the Digital Video Baby Monitor with thinners or other
solvents and chemicals - this may cause permanent damage to the product
which is not covered by the warranty.
•  Keep your Digital Video Baby Monitor away from hot, humid areas or strong
sunlight, and do not let it get wet.
•  Every...

Troubleshooting19
ENGLISH
6. Troubleshooting
Power Indicator on the parent unit does not come on
•  Check whether the parent unit is powered on.
•  Check whether the supplied battery pack is correctly installed and that they
are not drained.
•  Recharge the parent unit by connecting it to the electrical outlet.
Power/Link Indicator on the baby unit flashes
•  The baby unit may be not paired to the parent unit. Refer to section 3.11 to
pair the baby unit.
•  The parent unit and the baby unit may be out...

20Troubleshooting
Cannot view the video image of the object from the parent
unit
•  The LCD brightness may be set too low. Try to increase the brightness level.
Refer to section 3.5 for details.
•  The parent unit and the baby unit may be out of range with each other.
Reduce the distance between the units, but not closer than 3 feet.
•  Battery pack in the parent unit may be drained. Connect the parent unit to
the electrical outlet with the supplied power adapter for recharging.
Cannot hear sound or...
