Motorola Sd7500 Manual
Here you can view all the pages of manual Motorola Sd7500 Manual. The Motorola manuals for Camera are available online for free. You can easily download all the documents as PDF.
Page 11
1 SD7504 User Guide 1 Welcome Congratulations on your purchase of a Motorola SD7504 Series wireless camera. Check the contents listing on the product packaging to ensure that your purchase includes each of the items listed. Product registration is an important step toward enjoying your new Motorola product. Registering helps us facilitate wa rranty service, and permits us to contact you should your Motorola product require an update or other service. Registration is not required for...
Page 12
2 SD7504 User Guide 2 Camera Overview 1. Camera lens 2. Speaker 3. Microphone 4. Light sensor 5. Page/registration button 6. In use/page/registration indicator
Page 13
3 SD7504 User Guide 3 How to Use this Guide It is necessary to use a color or black and white handset to receive images and sound from your camera. This guide makes use of two fonts to distinguish between the FUNCTIONS and FEATURES/OPTIONS associated with the handsets and some base units. • FUNCTION keys are found on the handset and some base units. These keys allow you to perform act ions such as placing calls ( ON/FLASH ), ending calls ( OFF/CANCEL ), and connecting to ( CONNECT...
Page 14
4 SD7504 User Guide 4 Getting Started Battery Safety Instructions • Do not burn, disassemble, mutilate, or puncture the battery. The battery contains toxic materials that could be released, resulting in injury and/or explosion. • CAUTION: There is a risk of explosion if you replace the battery with an incorrect battery type. Use only the battery that came with your phone or an authorized replacement recommended by the manufacturer. • Keep batteries out of the reach of children. •...
Page 15
5 SD7504 User Guide 5 Installing the Camera Battery 1. Remove any stickers or inserts, if present. 2. Remove the battery door by pressing down on the indentation and sliding upward. 3. Plug the battery connector into the receptacle. (Make sure the black wire is on the right.) 4. Insert the battery into the battery compartment. 5. Replace the battery door. Black Red
Page 16
6 SD7504 User Guide 6 Selecting a Location for Your Camera After the camera battery is fully charged, you can disconnect the power cord and place the camera in any room you wish to monitor.
Page 17
7 SD7504 User Guide 7 Charging the Camera Battery 1. Insert the power cord into the back of the camera base. 2. Plug the power cord into an electrical outlet. 3. Place the base on a sturdy surface. NOTES: • The initial battery charge ti me is 10–12 hours. • A fully charged battery prov ides approximately three hours of viewing of time, or four hours of audio, and has approximately five days standby.
Page 18
8 SD7504 User Guide 8 Camera Indicators The LED on your wireless camera changes to indicate different actions. The table below details each change. LED Description Green (flashing quickly) The camera is not registered Green (solid) The camera is registered and charging, but not in use Red (flashing quickly) The camera is in the registration process Red (slow flash) The camera is being paged Red (solid) The camera is in use
Page 19
9 SD7504 User Guide 9 Registering Your New Camera Before you can use your new wireless camera, you must register it to your base unit. SD7500 Series base units allow you to register up to 12 devices (e.g., handsets, cameras, cell docks), and use up to four devices at one time. To register a new camera: 1. Ensure that your camera is plugged into an electrical outlet. 2. Press and hold the PAGE button on the camera. Release the button after approximately four seconds or until t he LED...
Page 20
10 SD7504 User Guide 10 Using Your New Camera All SD7500 Series handsets are compatible with your new camera. You can use the black and white or color handsets to monitor a room. Only the color handsets offer both audio and visual monitoring. NOTES: • All monitoring sessions automatically set to MUTE and in speakerphone mode . To turn the speakerphone off, press the handset’s SPKRPHONE button. • Use the handset’s volume control buttons to increase or decrease the sound. •...
