NEC Neax 2400 Imx Business Features And Specifications

NEAX2400 IMX Business Features and Specifications
NDA-24221, Issue 3
Page 171
Call Forwarding - Intercept / Announcement - Attendant C-75
C-75  Call Forwarding - Intercept / Announcement -
Attendant
General Description
This feature provides for interception of Attendant-originated calls that cannot be completed (unassigned station,
level, etc.). These calls are automatically routed to a recorded announcement informing the caller that an inoperative
number was reached.
Operating Procedure
No manual...

NEAX2400 IMX Business Features and Specifications
Page 172NDA-24221, Issue 3
C-76 Call Waiting Lamp - UCD
C-76  Call Waiting Lamp - UCD
General Description
This feature uses an LED indication, which is one of the programmable keys on the Dterm, to indicate when a call is
waiting to be answered in the UCD queue.
Operating Procedure
No manual operation is required.
Service Conditions
1. The UCD Call Waiting Lamp displays the status of the UCD group as follows:
Lamp On: One or more calls waiting in the UCD...

NEAX2400 IMX Business Features and Specifications
NDA-24221, Issue 3
Page 173
Call Waiting Lamp - UCD C-76
Interactions (cont’d)
7. If the overflow group is all busy, queuing takes place to the first group and the CALL WAITING LAMP-
UCD will light to indicate a queuing condition at the first group.
8. When a UCD station is assigned as the destination station of LDN Night Connection, this service cannot
be activated.
9. For the FCCS network, this feature is available only for UCD stations in the same node...

NEAX2400 IMX Business Features and Specifications
Page 174NDA-24221, Issue 3
C-81 Call Forwarding - I’m Here
C-81 Call Forwarding - I’m Here
General Description
This service feature permits the CALL FORWARDING - ALL CALLS feature to be set/cancelled from the target
station.
Operating Procedure
To set CALL FORWARDING - IM HERE from the target station:
1. Go off-hook; receive dial tone.
2. Dial the CALL FORWARDING - IM HERE access code (from the target station); receive special dial
tone.
3. Dial the...

NEAX2400 IMX Business Features and Specifications
NDA-24221, Issue 3
Page 175
Call Forwarding - I’m Here C-81
Service Conditions (cont’d)
12. When using the FCCS network, if the destination (target station) is a Dterm, CALL FORWARDING - I’M
HERE can be set or cancelled from a sub line of a Dterm. At that time, the transferred call terminates to the
My Line of the Dterm that sets the service.
13. When using the FCCS network, the service can be set or cancelled when the forwarding station is idle.
14. When...

NEAX2400 IMX Business Features and Specifications
Page 176NDA-24221, Issue 3
C-109 Centrex Compatibility
C-109 Centrex Compatibility
General Description
This feature allows a DTMF type telephone user engaged in a trunk call to send a hooking signal to the called office,
enabling the call to be transferred to another station in that office.
Operating Procedure
Station A is connected to Station B, accommodated in another office.
1. Station A presses switch hook; receives special dial tone of the called...

NEAX2400 IMX Business Features and Specifications
NDA-24221, Issue 3
Page 177
Call Forwarding - Don’t Answer To UCD Queue C-133
C-133 Call Forwarding - Don’t Answer To UCD Queue
General Description
This feature allows calls to a station that has set CALL FORWARDING-DONT ANSWER to a UNIFORM CALL
DISTRIBUTION group to be added to a UCD queue if all stations in the UCD group are busy. (Originally, calls
forwarded to a UCD group would receive reorder tone if all stations in the group were busy.)
Operating...

NEAX2400 IMX Business Features and Specifications
Page 178NDA-24221, Issue 3
C-146 Call Hold - Conference
C-146 Call Hold - Conference
General Description
This feature allows a user to establish a conference connection by adding a third party who is held on a multiline of
a Dterm to the existing two-party connection. The held call which is to be added may be a station or trunk call.
Operating Procedure
To operate from a Dterm:
1. Make a trunk/station call using line A on the Dterm.
2. Place the...

NEAX2400 IMX Business Features and Specifications
NDA-24221, Issue 3
Page 179
Call Hold - Conference C-146
Service Conditions (cont’d)
2. This service is available when the call is held by the Dterm HOLD key.
3. When the originally connected party (B) is placed on Exclusive Hold, this service is available only when
the D
term user (A) engages in the call with the third party (C).
4. When the D
term user (A) places the station or trunk (B) on hold, including Exclusive Hold, DUAL HOLD
[D-32D] cannot be...

NEAX2400 IMX Business Features and Specifications
Page 180NDA-24221, Issue 3
C-150 Call Block
C-150 Call Block
General Description
This feature is a part of Caller ID service. This feature restricts termination of incoming calls from the preassigned
calling numbers. This feature is available by designating the calling number by the MAT.
Call Block is used to restrict an incoming call that has a Restriction Number (Physical Station Number, telephone
number or the Caller ID number, which are preset by each...
