NEAX2400 IMX CCIS Features and Specifications
Page 106NDA-24222, Issue 3
I-18 Inter-Position Transfer - CCIS
I-18 Inter-Position Transfer - CCIS
General Description
This feature allows calls to be transferred from one Attendant Console to another through the CCIS network.
Operating Procedure
To transfer from Console A to Console B:
1. Attendant A presses the START key.
2. Attendant A dials the Attendant Console B Identification Number, or “0” for all Attendant Consoles.
3. The call is indicated at...

NEAX2400 IMX CCIS Features and Specifications
NDA-24222, Issue 3
Page 107
Look Ahead Routing - CCIS L-25
L-25  Look Ahead Routing - CCIS
General Description
This feature allows a station to dial a Public Switched Telephone Network (PSTN) call and has the capability of
looking ahead to seven directly-connected nodes in the CCIS network for an idle trunk.
Operating Procedure
1. Lift the handset; receive dial tone.
2. Dial the access code; receive second dial tone.
3. Dial the PSTN number.
4. The system...

NEAX2400 IMX CCIS Features and Specifications
Page 108NDA-24222, Issue 3
L-29 LDN Night Connection - CCIS
L-29 LDN Night Connection - CCIS
General Description
When an LDN incoming call arrives from a CCIS line or other outside line while the System is in Night Mode, this
service feature transfers the call to a transfer destination outside line, including CCIS lines, assigned for that LDN.
Operating Procedure
1. Attendants 1 & 2 in Node A set into Night mode using the NITE key; the Night lamp illuminates...

NEAX2400 IMX CCIS Features and Specifications
NDA-24222, Issue 3
Page 109
LDN Night Connection - CCIS L-29
Service Conditions
1. The ranking of this service feature within the Night Connection service is as follows:
 Night Connection Flexible.
 Night Connection Fixed.
 LDN Night Connection (This service).
 Night Connection Outside.
 Trunk Answer from Any Station (TAS) Connection.
 Busy Tone Connection.
2. It is possible to register individual transfer destinations for up to 16 LDNs per Tenant....

NEAX2400 IMX CCIS Features and Specifications
Page 110NDA-24222, Issue 3
M-34 Message Reminder - CCIS
M-34 Message Reminder - CCIS
General Description
This service feature allows Inter-Office Message Reminder when the calling station and the called station belong to
different PBXs in the CCIS network.
Operating Procedure
From Dterm to Dterm:
1. Dterm A and B are engaging in a call.
2. D
term C goes off-hook and dials the number for Dterm B; receives busy tone.
3. D
term C presses the MSG key and receives...

NEAX2400 IMX CCIS Features and Specifications
NDA-24222, Issue 3
Page 111
Message Reminder - CCIS M-34
Operating Procedure (cont’d)
5. Dterm B hangs up.
6. While the message lamp illuminates, D
term B goes off-hook or presses the SPEAKER key and receives
dial tone.
7. D
term B presses the MSG key and receives ringback tone. Redial is automatically made to Dterm C, and
Dterm C rings.
From a single-line Station to a Dterm:
1. Dterms A and B are engaging in a call.

N
E
C
NE
C
NE
C
Dterm (a)
[Node...

NEAX2400 IMX CCIS Features and Specifications
Page 112NDA-24222, Issue 3
M-34 Message Reminder - CCIS
Operating Procedure (cont’d)
2. Station C goes off-hook and dials the number for Dterm B; receives busy tone.
3. Station C switch hook flashes; receives special dial tone.
4. Station C dials the MESSAGE REMINDER access code; receives service set tone. The MESSAGE lamp
on D
term B illuminates, indicating that the message has been set.
5. D
term B hangs up.
6. While the message lamp illuminates, D
term B...

NEAX2400 IMX CCIS Features and Specifications
NDA-24222, Issue 3
Page 113
Message Reminder - CCIS M-34
Operating Procedure (cont’d)
7. Dterm B presses the MSG key and receives ringback tone. Redial is automatically made to Station C and
Station C rings.
Service Conditions
1. A message can be sent out only when the called station is either idle or busy.
2. A message can be sent out during ringing, recall from Call Transfer-All Calls, or recall from Consultation
Hold-All Calls.
3. A maximum of four...

NEAX2400 IMX CCIS Features and Specifications
Page 114NDA-24222, Issue 3
M-34D Message Reminder - Dterm - CCIS
M-34D Message Reminder - Dterm - CCIS
General Description
This feature allows a Dterm to leave a MESSAGE REMINDER at a Dterm in a different node in the CCIS network.
Operating Procedure
To activate MESSAGE REMINDER - CCIS from a Dterm to an idle or busy Dterm:
1. Lift the handset; receive dial tone.
2. Dial the desired D
term at the distant office; receive ringback tone or busy tone.
3. Press...

NEAX2400 IMX CCIS Features and Specifications
NDA-24222, Issue 3
Page 115
Message Reminder - Dterm - CCIS M-34D
Service Conditions
1. This feature is only available between two Dterm sets that both have the MESSAGE feature key. If a
message is directed to a single line or a Dterm that does not have the MESSAGE REMINDER feature, the
calling stations LCD displays:
2. Messages cannot be sent while engaged in calling or recall from CALL TRANSFER - ALL CALLS [C-
11] [C-50] or from CONSULTATION HOLD - ALL...
