NDA-24307 CHAPTER 3 Page 223 Issue 1 SYSTEM MESSAGES This message displays when the IOC card fails. ➀ IOC circuit card No. ➁ Cause for the fault 1: XXXX 0000 0000 0000 2: 0000 0000 0000 0000 3: 0000 0000 0000 0000 ➀ ➁ 4: 0000 0000 0000 0000 5: 0000 0000 0000 0000 6: 0000 0000 0000 0000 7: 0000 0000 0000 0000 8: 0000 0000 0000 0000 9: 0000 0000 0000 0000 b0 b4 b3 b2 b1 b0 Default Alarm: SUP16-TIOC Failure (Temporary)Default Grade: 1Grade Modified: Lamp Modified: b0: 0/1 = No. 0/No. 1 b0: 0/1 = -/COP...
Page 252
CHAPTER 3 NDA-24307 Page 224 Issue 1 SYSTEM MESSAGES This message displays when the IOC card failure, observed in the message [16-T], is detected more than eight times a day. ➀ IOC circuit card No. ➁ Cause for the fault See Chapter 4 for the Circuit Card Replacement Procedure. 1: XXXX 0000 0000 0000 2: 0000 0000 0000 0000 3: 0000 0000 0000 0000 ➀ ➁ 4: 0000 0000 0000 0000 5: 0000 0000 0000 0000 6: 0000 0000 0000 0000 7: 0000 0000 0000 0000 8: 0000 0000 0000 0000 9: 0000 0000 0000 0000 b0 b4 b3 b2 b1 b0...
Page 253
NDA-24307 CHAPTER 3 Page 225 Issue 1 SYSTEM MESSAGES This message displays when the user uses Follow Phone (SWAP) service. ➀ Error code 1: XXXX XXXX XXXX XX00 2: XXXX XXXX XXXX 00XX 3: XXXX 0000 0000 0000 ➀ ➁ ➂ ➃ ➄ ➅ ➆ ➇ ➈ ➉ 1112 13 14 14 4: 0000 0000 0000 0000 5: 0000 0000 0000 0000 6: 0000 0000 0000 0000 7: 0000 0000 0000 0000 8: 0000 0000 0000 0000 9: 0000 0000 0000 0000 b7 b6 b5 b4 b3 b2 b1 b0 ERROR CODE (HEX)FA I L U R EERROR CODE (HEX)FAILURE 00 Normal End 16 Called station is busy 01 MG unmatch...
Page 254
CHAPTER 3 NDA-24307 Page 226 Issue 1 SYSTEM MESSAGES ➁ Tenant No. of the calling station ➂ Accommodated location of the calling station after Follow Phone service ➃ Accommodated location of the calling station after Follow Phone service 09 - 34 Data Memory read error 10 Calling or Called D term has Data Line 35 Data Memory swap failure 11 Calling or Called D term has OAI function key36 OAI Terminal Information swap failure (CM Data) 12 Calling or Called station is Agent/ Supervisor (ACD)37 OAI...
Page 255
NDA-24307 CHAPTER 3 Page 227 Issue 1 SYSTEM MESSAGES ➄ ~ ➆ Station No. of the calling station ➇ Tenant No. of the called station ➈ Accommodated location of the called station ➉ Accommodated location of the called station 11 ~ 13 Station No. of the called station 14 Data Analyzed by NEC Engineers b7 b6 b5 b4 b3 b2 b1 b0 b7 b6 b5 b4 b3 b2 b1 b0 b7 b6 b5 b4 b3 b2 b1 b0 b7 b6 b5 b4 b3 b2 b1 b0 b7 b6 b5 b4 b3 b2 b1 b0 b4-b7b0-b3 ➄DC0 DC1 ➅DC2 DC3 ➆DC4 DC5 b0-b3: Tenant No. (1-15) b0-b7: Tenant No. (over...
Page 256
CHAPTER 3 NDA-24307 Page 228 Issue 1 SYSTEM MESSAGES This message displays when the MBR switch on the CCH/DCH card has turned ON. ➀ CCH/DCH Card Mounting Location ➁ CKT No. 1: XXXX 0000 0000 0000 2: 0000 0000 0000 0000 3: 0000 0000 0000 0000 ➀ ➁ 4: 0000 0000 0000 0000 5: 0000 0000 0000 0000 6: 0000 0000 0000 0000 7: 0000 0000 0000 0000 8: 0000 0000 0000 0000 9: 0000 0000 0000 0000 b7 b6 b5 b4 b3 b2 b1 b0 b1 b0 Default Alarm: NON17-ACCH MBR Key Turn ONDefault Grade: 3Grade Modified: Lamp Modified:...
Page 257
NDA-24307 CHAPTER 3 Page 229 Issue 1 SYSTEM MESSAGES This message displays when the MBR switch on the CCH/DCH card has turned OFF. ➀ CCH/DCH Card Mounting Location ➁ CKT No. 1: XXXX 0000 0000 0000 2: 0000 0000 0000 0000 3: 0000 0000 0000 0000 ➀ ➁ 4: 0000 0000 0000 0000 5: 0000 0000 0000 0000 6: 0000 0000 0000 0000 7: 0000 0000 0000 0000 8: 0000 0000 0000 0000 9: 0000 0000 0000 0000 b7 b6 b5 b4 b3 b2 b1 b0 b1 b0 Default Alarm: NON17-BCCH MBR Key Turn OFFDefault Grade: 3Grade Modified: Lamp Modified:...
Page 258
CHAPTER 3 NDA-24307 Page 230 Issue 1 SYSTEM MESSAGES This message displays when the MB switch on the CCH/DCH card has turned ON when extracting or inserting a circuit card or at PM initialization, etc. ➀ CCH/DCH Card Mounting Location 1: XX00 0000 0000 0000 2: 0000 0000 0000 0000 3: 0000 0000 0000 0000 ➀ 4: 0000 0000 0000 0000 5: 0000 0000 0000 0000 6: 0000 0000 0000 0000 7: 0000 0000 0000 0000 8: 0000 0000 0000 0000 9: 0000 0000 0000 0000 b7 b6 b5 b4 b3 b2 b1 b0 Default Alarm: NON17-CCCH MB Key Turn...
Page 259
NDA-24307 CHAPTER 3 Page 231 Issue 1 SYSTEM MESSAGES This message displays when the MB switch on the CCH/DCH card has turned OFF when extracting or inserting a circuit card or at PM initialization, etc. ➀ CCH/DCH Card Mounting Location 1: XX00 0000 0000 0000 2: 0000 0000 0000 0000 3: 0000 0000 0000 0000 ➀ 4: 0000 0000 0000 0000 5: 0000 0000 0000 0000 6: 0000 0000 0000 0000 7: 0000 0000 0000 0000 8: 0000 0000 0000 0000 9: 0000 0000 0000 0000 b7 b6 b5 b4 b3 b2 b1 b0 Default Alarm: NON17-DCCH MB Key Turn...
