Page 21
2 [ 8 ] To find the serial number, you have to remove the battery. Refer to “Remove the battery” on page 12 for step-by-step instructions on this procedure. Finally, if you are calling about any type of phone accessory, please have the accessory available. For example, if you are calling about a headset, please have it handy. This way, if you are asked a specific question about the accessory, it will be available for quick reference. Nokia Customer Care Center, USA Nokia Inc. 7725 Woodland Center...
Page 22
[ 9 ]Before you begin 3 3. Before you begin Before you begin using your phone, you need to perform several tasks. This section tells you how to complete these tasks. • Prepare your phone for use • “Install the SIM card” (see below). • “Install the battery” on page 10. • “Charge the battery” on page 10. To find out how to remove a battery, refer to “Remove the battery” on page 12. Remove the back cover 1 &2 Press the back cover release button and slide the cover as shown. 3 Lift the cover off the...
Page 23
3 [ 10 ] Notes about SIM cards • Keep all miniature SIM cards out of the reach of small children. • The SIM card and its contacts are easily damaged by scratches or bending, so be careful when handling, inserting, or removing the card. • You must remove the battery to access the SIM card. Always make sure that the phone is switched off before you remove the battery. Install the battery 1Place the battery in the compartment with the label side facing up and the golden contact area aligned with the...
Page 24
[ 11 ]Before you begin 3 2Connect the charger to a standard wall outlet. The battery power indicator (or battery bar) appears on the screen and starts scrolling. 3When the battery is 80% charged the battery bar stops scrolling. Battery full appears also, if the phone is on. To obtain 100% battery capacity, allow another 2 hours for a “trickle” or “maintenance” charge. 4Disconnect the charger from the phone. If the battery is completely empty, it might take a few minutes before the battery bar...
Page 25
3 [ 12 ] • The bars on the screen stop scrolling and remain constant when the phone is charged. If you leave the phone connected to the charger, the battery receives an additional charge. Note: The battery will accept a trickle charge for an additional two hours. See “Reference information” on page 111 for more information on batteries. Charging time depends on the charger and battery. For example, charging time for the BLB-3 battery with the ACP-7U charger is about 4 hours. Remove the battery...
Page 26
[ 13 ]Before you begin 3 6Lift out the battery. Note: When you remove and replace the battery, you must reset the phone’s clock. See “Set up the clock” on page 68. • Important battery information Important: Your phone is powered by a rechargeable battery. Use only batteries approved by Nokia and recharge your battery only with the chargers approved by Nokia. Never use any charger or battery which is damaged. The battery can be charged and discharged hundreds of times but it will eventually wear out....
Page 27
4 [ 14 ] 4. About your phone • Switch on your phone • Press and hold for two seconds. The phone might ask for a Personal Identification (PIN) code or a security code. See “PIN and PUK codes” on page 71 for more information. Warning! Do not switch on the phone in places where wireless phone use is prohibited or where the use of the phone could cause interference or danger. Important: As with any other radio transmitting device, do not touch the antenna unnecessarily when the phone is switched...
Page 28
[ 15 ]About your phone 4 • About the Start screen When you turn on your phone, the first screen that appears is the Start screen. In the middle of the Start screen, you see information indicating which wireless network your phone uses. This information can vary between phones. Other indicators and icons appear on this Start screen and are described in “Icons” on page 16. About indicators and icons On your phone, you have two types of identifiers: indicators and icons. Indicators Indicators show...
Page 29
4 [ 16 ] Icons Icons are graphical representations of a specific item or situation. For example, this icon may appear when you have a voice message waiting to be heard. (Some systems use a different method.) The rest of this section shows examples of each icon that can appear on your phone and tells you what these icons indicate. Line 1 is selected for outgoing calls. Line 2 is selected for outgoing calls. You have an active call. You have one or more new voice messages. (Some carriers may use a...
Page 30
[ 17 ]About your phone 4 Characters entered will be lowercase letters. Press to switch letter case. Characters entered will be numbers. (When entering letters, switch to numbers by pressing and holding .) You are in “special character” mode. Select a character, then press Use . (When entering letters, press and hold the key to see the special characters menu.) You are in predictive text mode. You are in predictive text mode. Characters entered will be uppercase letters. Press to switch letter...
