Panasonic Cf Y2dwazzkm Owners Manual

31
Troubleshooting
When you want to display
the fonts or icons at a larger
size
When a video such as an
MPEG file and a DVD video
is being played with
WinDVD or Windows
® Me-
dia Player, the display desti-
nation cannot be switched
using
Fn   +   F3
During simultaneous dis-
play, the screen of the exter-
nal display becomes disor-
dered
Change the size of the icons, etc. using “Icon Enlarger” (  “Icon Enlarger”).
You can also change the settings as follows (for more details, refer to the Windows Help)....

32
Troubleshooting
Dealing with Problems (Summary)
Is Acrobat Reader installed?
If Acrobat Reader is not installed, run [c:\util
eader\acroreader51_enu\
_full.exe] in [start]
- [Run] to reinstall the program.  When installing the program, do not change the installa-
tion destination folder.  If the destination folder is changed, the Reference Manual cannot
be opened from [start] menu.
 Reference Manual
The Reference Manual is
not displayed
 Reinstalling Bs Recorder/Bs CLiP
When reinstalling, the input
of...

33
Troubleshooting
No response
When trying to play back
video files using Windows®
Media Player, the message
[Codec required] appears,
and the file cannot be played
back
The shortcut icon for the
Windows® Media Player is
not displayed on the desktop
Two shortcut icons for the
Windows® Media Player are
displayed on the desktop
Cannot operate Fn key
Press   Ctrl   +   Shift   +   Esc    to open Task Manager and close the software application
which is not responding.
After shutting down by sliding the power...

34
Troubleshooting
Reinstalling Software
Before Reinstallation
Preparing
You will need the Product Recovery DVD-ROM (included).
Important
Before the reinstallation procedure, remove all peripherals.
Be sure the AC adaptor is connected until the reinstallation procedure is completed.
Even if reinstallation is executed, the number of times that the DVD video region code can be set will not be returned to
the state set at the time of factory shipment.
Reinstalling
When reinstallation procedure is performed,...

35
Troubleshooting

If you select [1] or [2], the message [The Backup function
has been enabled. If [Recovery] is executed, the Backup
function will be disabled, and your Backup data will be
lost.] appears.  In this case, press
Y   .
If the message [Computer must be rebooted in order to
execute [Recovery.]] appears, press
R   .
9
At the confirmation message, press   Y   .
The operation of reinstallation for the hard disk starts auto-
matically. (The operations take about 20 minutes.)
After the...

36
Appendix
LIMITED USE LICENSE AGREEMENT
THE SOFTWARE PROGRAM(S) (“PROGRAMS”) FURNISHED WITH THIS PANASONIC® PRODUCT (“PRODUCT”)
ARE LICENSED ONLY TO THE END-USER (“YOU”), AND MAY BE USED BY YOU ONLY IN ACCORDANCE WITH
THE LICENSE TERMS DESCRIBED BELOW. YOUR USE OF THE PROGRAMS SHALL BE CONCLUSIVELY DEEMED
TO CONSTITUTE YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE.
Matsushita Electric Industrial Co., Ltd. (“MEI”) has developed or otherwise obtained the Programs and hereby licenses
their use to you. You...

37
Appendix
A. MEI vous octroie par les présentes le droit et la licence personnels, non cessibles et non exclusifs dutiliser les
Logiciels conformément aux termes, clauses et conditions de ce Contrat. Vous reconnaissez ne recevoir quun
droit limité dutiliser les Logiciels et la documentation les accompagnant et vous vous engagez à nobtenir aucun
droit de titre, propriété ni aucun autre droit vis-à-vis des Logiciels et de la documentation les accompagnant ni vis-
à-vis des algorithmes, concepts, dessins,...

38
Appendix
Hard Disk Backup Function
The hard disk backup function creates a backup area (storage area) on the hard disk. This area is to back up (store) hard disk
contents or restore backed up contents to their original locations.
By backing up the data on your hard disk to a backup area, you can protect your data from loss or damage resulting from operational
errors or other factors.  Also, you can back up or restore hard disk contents using this computer alone, without having to use other
media or...

39
Appendix
1Turn the computer on, and press   F2   while [Panasonic] boot screen is displayed.
The Setup Utility will start up.
If a password has been set, enter the Supervisor Password.
You cannot register [Boot] menu with a User Password.
Check to ensure that [CD/DVD Drive Power] is set to [On] in [Main] menu.
If it has been set to [Off], reset to [On]. In this case as well, refer to operations in “When disc
cover does not open” in Step 3.
2
Select [Boot] menu, then select [CD/DVD Drive] and press...

40
Appendix
Hard Disk Backup Function

Select [2], enter the partition size (GB), and press   Enter   .
• You can cancel this operation by pressing    0   .
• The data partition size will be the maximum settable size less the number entered above.
The maximum settable size will differ depending on models.
8
At the confirmation message, press    Y   .
The backup area is then created.
9When the message [You must reboot in order to enable the Backup function.] appears, remove
the Product Recovery DVD-ROM,...
