- 131 -
Connecting to other equipment
The recorded still pictures can be played back on a TV with an SD Memory Card slot.
•Depending on the TV model, pictures may not be displayed on the  full screen.•The file format of the motion pictures that can be played back differs depending on the TV model.
•In some cases, panorama pictures cannot be played back. Also, a uto-scroll playback of
panorama pictures may not work.
•For cards compatible with playback, refer to the operating inst ructions of the TV.

- 132 -
Connecting to other equipment
Saving still pictures and motion pictures on your
PC
You can transfer the pictures in the camera to a PC by connecting the camera and the PC.
•Some PCs can read directly from the card removed from the camera. For details, refer to the
operating instructions of your PC.
•If the computer being used does not support SDXC Memory Cards, a message prompting you
to format may appear.
(Doing so will cause recorded images to be erased so do not cho ose to format.)
If the...

- 133 -
Connecting to other equipment
1Connect the computer and camera with the USB connection cable
(supplied).
•Please turn this unit on and your PC before connecting.•Check the directions of the connectors, and plug them straight in or unplug them straight out.
(Otherwise the connectors may bend out of shape, which may cause malfunction.)
•Do not use any other USB connection cables except the supplied  one or a genuine
Panasonic USB connection cable (DMW-USBC1: optional).
2Press 4 to select [PC],...

- 134 -
Connecting to other equipment
∫About the folder structure of the camera
The content (folder structure) of the built-in memory of the ca mera/the card is displayed on a
PC as follows:
•
A new folder is created when pictures are taken in the followin g situations.–When a card containing a folder with the same folder number has  been inserted (Such as when
pictures were taken using another maker of camera)
–When there is a picture with file number 999 inside the folder
∫ Connection in the PTP...

- 135 -
Connecting to other equipment
Printing the Pictures
If you connect the camera to a printer supporting PictBridge, you can select the pictures to be
printed out and instruct that printing be started on the camera’s monitor.
•
Some printers can print directly from the card removed from the  camera. For details, refer to the
operating instructions of your printer.
Preparations:
Turn on the camera and the printer.
Remove the card before printing the pictures from the built-in  memory.
Check print...

- 136 -
Connecting to other equipment
1Press 3.
2Press 3/4 to select an item and then press [MENU/SET].
3Press 3 to select [Print start] and then press [MENU/SET].
•If the print check screen has appeared, select [Yes], and print  the pictures.
•Refer to P137 for the items which can be set before starting to print the pi ctures.•Disconnect the USB connection cable after printing.
Selecting a single picture and printing it
1Press 2/1 to select the picture and then press
[MENU/SET].
2Press 3 to select...

- 137 -
Connecting to other equipment
Select and set the items both on the screen in step 2 of the “Selecting a single picture
and printing it” and in step
3 of the “Selecting multiple pictures and printing them”
procedures.
•
When you want to print pictures in a paper size or a layout whi ch is not supported by the camera, set
[Paper Size] or [Page Layout] to [ {] and then set the paper size or the layout on the printer.
(For details, refer to the operating instructions of the printe r.)
•If the...

- 138 -
Connecting to other equipment
•Paper sizes not supported by the printer will not be displayed.
[Paper Size]
{Settings on the printer are prioritized.
[L/3.5 qk5q]
89 mmk127 mm
[2L/5 qk7q] 127 mmk178 mm
[POSTCARD] 100 mmk148 mm
[A4] 210 mmk297 mm
[A3] 297 mmk420 mm
[10 k15cm] 100 mmk150 mm
[4 qk6 q] 101.6 mmk152.4 mm
[8 qk10q ] 203.2 mmk254 mm
[LETTER] 216 mmk279.4 mm
[CARD SIZE] 54 mmk85.6 mm

- 139 -
Connecting to other equipment
•An item cannot be selected if the printer does not support the page layout.
∫Layout printing
When printing a picture several times on 1 sheet of paper
For example, if you want to print the same picture 4 times on 1  sheet of paper, set
[Page Layout] to [ ä] and then set [Num.of prints] to 4 for the picture that you wan t to print.
When printing different pictures on 1 sheet of paper
For example, if you want to print 4 different pictures on 1 shee t of paper, set...

- 140 -
Others
Screen Display
∫In recording
1 Recording Mode
2 Recording Quality  (P86)
Picture Size  (P75)
3 Flash  (P55)
4 Optical Image Stabilizer  (P84)
Jitter alert (P24) :
5 White Balance  (P77)
Creative control adjustment display
(P61) :
6 Battery indication  (P14)
7 Burst  (P82)
8 Intelligent Exposure  (P81)
9 Focus  (P31)
10 AF area  (P31)
11 Self-timer  (P59)
12 Shutter speed  (P30)
13 Aperture value  (P30)
14 ISO sensitivity  (P76) 15 Exposure compensation
(P60)
AF assist lamp  (P83):
16...
