- 131 -
Wi-Fi
∫Check or change the acquired login ID/password
Preparation:
To change the “LUMIX CLUB” password on the camera, access the “LUMIX CLUB” website
from your smartphone or PC and change t he “LUMIX CLUB” password in advance.
1Select [Wi-Fi Setup] in the [Wi-Fi] menu.  (P41)2Press 3/4  to select [LUMIX CLUB], and press [MENU/SET].3Press  3/4  to select [Add/Change Account], and press [MENU/SET].
4Press 3/4 to select [Change Login ID], and press [MENU/SET].•The login ID and password are...

- 132 -
Wi-Fi
∫Check the “LUMIX CLUB” terms of use
Check the details if the terms of use have been updated.
1Select [Wi-Fi Setup] in the [Wi-Fi] menu.  (P41)2Press 3/4  to select [LUMIX CLUB], and press [MENU/SET].3Press  3/4  to select [Terms of use], and press [MENU/SET].
•The camera will connect to the network and the terms of use will be displayed. Close the menu
after checking the terms of use.
∫ Delete your login ID and account from the “LUMIX CLUB”
Delete the login ID from the camera when...

- 133 -
Wi-Fi
Images can be sent to the AV device of relatives and acquaintances via “LUMIX CLUB”.
•See the following site for AV device that is compatible with “LUMIX CLUB”.
http://panasonic.jp/support/global/cs/dsc/ (This Site is English only.)
1Select [Wi-Fi Setup] in the [Wi-Fi] menu.  (P41)
2Press 3/4 to select [External AV device], and press [MENU/SET].
3Press 3/4 to select [Add new device], and press [MENU/SET].
4Enter the address number and select [Set].
•Refer to “Entering Text” (P71)  for...

- 134 -
Wi-Fi
Any desired [Wi-Fi] menu can be set to the [Wi-Fi] button.
1Select [Wi-Fi Setup] in the [Wi-Fi] menu. (P41)
2Press 3/4 to select [Wi-Fi Button], and press [MENU/SET].
3Press 3/4 to select item, and press [MENU/SET].
•Following items can be selected.
Note
•The [Wi-Fi] button set to the following functions does not work in the Recording Mode.–[Send Image]–[Wireless TV Playback]
–[Wireless Print]
[Wi-Fi Button]
[Show Wi-Fi Menu] [Wireless TV Playback] (P120)
[Remote Control]  (P109) [Wireless...

- 135 -
Wi-Fi
To prevent incorrect operation or use of the Wi-Fi function by a third party and to protect
saved personal information, it is recommended that you protect the Wi-Fi function with a
password.
Setting a password will automatically display the password input screen when the Wi-Fi
function is used.
1Select [Wi-Fi Setup] in the [Wi-Fi] menu. (P41)
2Press 3/4 to select [Wi-Fi Password], and press [MENU/SET].
3Press 3/4 to select [Setup], and press [MENU/SET].
4Enter a password and press...

- 136 -
Wi-Fi
Displays the MAC address set for the camera.
A “MAC Address” is a unique address that is used to identify network equipment.
1Select [Wi-Fi Setup] in the [Wi-Fi] menu.  (P41)
2Press 3/4 to select [MAC Address], and press [MENU/SET].
•The MAC address of the camera is displayed. Close the menu after checking the address.
•For details, refer to  P48.
•The “LUMIX CLUB” login ID is separate to [Reset Wi-Fi Settings] in the Setup Menu, and cannot be
deleted. Instead, delete it with [Delete...

- 137 -
Connecting to other equipment
Playing Back Pictures on a TV Screen
Pictures recorded with this unit can be played back on a TV screen.
•Please use the optional AV cable (DMW-AVC1).
Preparations:
Set the [TV Aspect]. (P48)
Turn this unit and the TV off.
1Connect the camera and a TV.
•Check the directions of the connectors, and plug th em straight in or unplug them straight out.
(Otherwise the connectors may bend out of shape, which may cause malfunction.)
•Always use a genuine Panasonic AV cable...

- 138 -
Connecting to other equipment
The recorded still pictures can be played back on a TV with an SD Memory Card slot.
•Depending on the TV model, pictures may not be displayed on the full screen.•Motion pictures cannot be played back. To play back motion pictures, connect the camera to the
TV with the AV cable (optional).
•In some cases, panorama pictures cannot be played back. Also, auto-scroll playback of
panorama pictures may not work.
•For cards compatible with playback, refer to the operating...

- 139 -
Connecting to other equipment
Saving still pictures and motion pictures on your PC
You can transfer the pictures in the camera to a PC by connecting the camera and the PC.
•Some PCs can read directly from the card removed from the camera. For details, refer to the
operating instructions of your PC.
•If the computer being used does not support SDXC Memory Cards, a message prompting you
to format may appear. (Doing so will cause recorded images to be erased so do not choose to
format.)
If the...

- 140 -
Connecting to other equipment
1Connect the computer and camera with the USB connection cable
(supplied/optional).
2Press 3/4 to select [PC], and then press [MENU/SET].
3Copy the images to a PC using “ PHOTOfunSTUDIO ”.
•Do not delete or move copied files or folders in Windows Explorer. When viewing in
“ PHOTOfunSTUDIO ”, you will not be able to play back or edit.
Note
•“ PHOTOfunSTUDIO ” is not compatible with Mac.
•Use a battery with sufficient battery power or the AC adaptor (optional). If...
