Panasonic Expandable Digital Cordless Camera Manual

Please read these Operating Instructions before using the unit and save
for future reference.
For assistance, visit our website:
http://www.panasonic.com/phonehelp for customers in the U.S.A. or
Puerto Rico.This cordless camera is an accessory unit for use with Panasonic
base units KX-TG5761/KX-TG5766/KX-TG5767/KX-TG5771/KX-
TG5776/KX-TG5777. You must register this cordless camera with
your base unit before it can be used.
Camera monitoring requires a color display handset (KX-TGA571).
5.8 GHz...

Table of Contents
2For assistance, please visit http://www.panasonic.com/phonehelp
Introduction
Introduction. . . . . . . . . . . . . . . . . . . . . . . 3
Accessory information  . . . . . . . . . . . . . . 4
Important safety instructions  . . . . . . . . . 5
For best performance . . . . . . . . . . . . . . . 6
Preparation
Controls  . . . . . . . . . . . . . . . . . . . . . . . . . 7
Setting up the cordless camera  . . . . . . . 8
Symbols used in these operating
instructions . . . . . . . . . . . . . ....

Introduction
For assistance, please visit http://www.panasonic.com/phonehelp3
Introduction
Thank you for purchasing the Panasonic 5.8 GHz expandable digital
cordless camera.
We recommend keeping a record of the following information for future reference.
Attach your purchase receipt here.
Feature highlight
Camera monitoring using the color display handset
Important:
LThis unit is compatible only with the 5.8 GHz expandable digital cordless handset KX-
TGA571 (color display type). For further information...

Introduction
4For assistance, please visit http://www.panasonic.com/phonehelp
Accessory information
Included accessories
Sales and support information
LTo order these accessories, call 1-800-332-5368.
LTTY users (hearing or speech impaired users) can call 1-866-605-1277.
No.Accessory itemOrder numberQuantity
1AC adaptor for cordless camera PQLV235Z 1
2Wall-mounting adaptor for cordless
cameraPQLP10267Z 1
3Call button for cordless camera PQLP10270Z 1
123
TGA573(e).book  Page 4  Monday, April 24, 2006...

Introduction
For assistance, please visit http://www.panasonic.com/phonehelp5
Important safety
instructions
When using the product, basic safety
precautions should always be followed to
reduce the risk of fire, electric shock, or
personal injury.
1. Read and understand all instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. After cleaning away the dust on the
lens, wipe the lens with a cotton bud.
6. Do not install near any heat sources
such as radiators,...

Introduction
6For assistance, please visit http://www.panasonic.com/phonehelp
For best performance
Avoiding noise
This unit communicates using radio
waves.
For maximum distance and noise-free
operation, we recommend placing the
product away from electrical appliances.
Environment
LKeep the product away from electrical
noise generating devices, such as
fluorescent lamps and motors.
LThe product should be kept free from
excessive smoke, dust, high
temperature, and vibration.
LThe product should not...

Preparation
For assistance, please visit http://www.panasonic.com/phonehelp7
Controls
Understanding the cordless camera indicator
The cordless camera indicator shows the status as follows. AAntenna
BCamera lens
CMIC (Microphone)
D{Call button}EIndicator
FDIP switches
GSpeaker
HPROG. (Program)
StatusDescription
Red (flashing rapidly)LThe cordless camera is not registered. Register the
cordless camera (page 12).
LThe cordless camera is out of range. Locate the cordless
camera near the base unit....

Preparation
8For assistance, please visit http://www.panasonic.com/phonehelp
Setting up the cordless camera
Connecting the AC adaptor and the call button
Connect the AC adaptor cord by pressing the plug firmly (A). Connect the call button cord
until it clicks into the unit (B).
LUse only the included Panasonic AC adaptor PQLV235.

Note:
LWhen the AC adaptor is connected, the indicator lights in red then starts flashing.
LThe AC adaptor must remain connected at all times. (It is normal for the adaptor...

Preparation
For assistance, please visit http://www.panasonic.com/phonehelp9
Adjusting the cordless camera lens angle
Aim the camera lens by pushing the tab (A) and rotating the lens forward or backward.
LUsing the handset, confirm that the area you want to monitor from the cordless camera
is displayed (page 13).
Note:
LDo not touch the camera lens (page 7).
A
Approx.
40°
Approx.
40°
TGA573(e).book  Page 9  Monday, April 24, 2006  2:05 PM

Preparation
10For assistance, please visit http://www.panasonic.com/phonehelp
Setting the DIP switches
You can set the following functions by using the DIP switch 1 to 3.
Slide each switch with a pointed object such as a pen as necessary.
After repositioning the DIP switches to your preferred settings, unplug the AC adaptor then
reconnect it. The cordless camera is reset to these settings.
*1 Slide the switch to down.
Displaying the image upside down (DIP switch 1)
To turn the camera image upside down,...
