Here you can view all the pages of manual Panasonic Hd Visual Communication Unit Kx Vc500 Operating Manual . The Panasonic manuals for Communications System are available online for free. You can easily download all the documents as PDF.
Page 11
Data Security We recommend observing the security precautions described in this section, in order to prevent the disclosure of sensitive information. Panasonic is not responsible for any damages caused by improper use of this device. Preventing Data Loss Keep a separate record of all information stored in the contact list. Preventing Data Disclosure • Do not place this device in a location that can be accessed or removed without authorization. • If important information is saved on this device, store it...
Page 12
Federal Communications Commission Requirements Federal Communications Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with...
Page 13
Part Names and Usage Main Unit (Front) Power LED Shows the power status. The LED is red when the power is on and off when the power is off. Remote Control Signal Receiver Receives Remote Control signals. The maximum range of reception is approximately 8 m (26.2 ft) from front of the KX-VC500, and approximately 3 m (9.8 ft) from 20° on each side, total 40 °.Start button Press to make or manually answer video conference calls. ( Page 22, Page 28)End button Press to end a video conference call. Power...
Page 14
Main Unit (Back) RS-232C terminal This terminal is not available for use. MIC jack Used to connect the Boundary Microphone (optional) ( Page 16).L/R jack Used to connect general-purpose microphones (not for the Boundary Microphone). LAN jack Connect a LAN cable. Camera Control terminal This terminal is not available for use. Main Camera terminal Connect the main video camera with an HDMI cable. Sub Camera terminal Used to connect a second, sub video camera with an HDMI cable for sharing video contents...
Page 15
Remote Control Document Version 2010-03 Operating Manual 15 PreparationPress to transmit the sub video cameras images to the other party. This operation is only available during a video conference call. (Page 40) Press to display/hide information about the other party, guide area and duration, during a call. (Page 21) Press to change the layout of the screen during a call. (Page 30) Press to return to the main camera after showing images from a computer or sub video camera. (Page 38, 40)...
Page 16
Boundary Microphone (Optional Accessory) Boundary Microphone (Proprietary cable included. Cable length: approx. 8.5 m [approx. 28 ft]) Part No.:KX-VCA001NA MIC Mute button Press to mute your own voice so that other video conference call participants cannot hear you. (Page 34) LEDs Indicate the operational status of the Boundary Microphone. Red (on): Microphone is muted Green (on): Transmitting Orange (blinking in 1s intervals): Starting up Off: No transmission in progress Note •Up to 4 Boundary...
Page 17
LED Patterns LEDs indicate the operational status of the KX-VC500, as follows: LED pattern Status Slow blue flashing •Starting up • Idle state Blue on •In a video conference call (including when dialing, receiving a video conference call, and being disconnected) Red on •An error has occurred. • Maintenance is being performed. Red flashing •A serious error has occurred. Off •Power is off • In screen standby mode Screen Standby When there is no video conference call transmission, and the KX-VC500 or...
Page 18
Turning the Power On/Off Note •Make sure that peripheral devices (e.g., display, main video camera) are turned on. 1 Press the [Power] button on the front of the KX-VC500. • The Power LED and all of the One-Touch Connection button LEDs turn on. Then, the One-Touch Connection button LEDs turn off, the Status LED starts flashing blue slowly, and the Home screen is displayed. • When the power is turned off, the power LED turns off. 18 Operating Manual Document Version 2010-03 Preparation 1
Page 19
Screen Display Home Screen (Idle Screen) Displayed when the power is turned on. Also displayed when the [Home] button is pressed on the KX-VC500 or on the remote control. Main Video Camera Image Displays the video from the main video camera. Unit Information Displays the KX-VC500 ’s name and IP address. Site/Group Displays the name/group name assigned to One-Touch Connection number 1 through 5. If the name is too long to display, it will be shortened and ended with "...".Guide Displays...
Page 20
Menu Screen (Idle Screen) Displayed when [Menu] is pressed on the remote control. Displays operations you can perform and settings you can change. Main Video Camera Image Displays the video from the main video camera. Unit Information Displays the KX-VC500 ’s name and IP address.Guide Displays operations you can perform with the remote control when performing features or changing settings. Menu List Displays the various functions you can use and settings available to change. Status Indication The status...
