Here you can view all the pages of manual Panasonic Indoor Pan Tilt Head Awrc400n Operating Instructions . The Panasonic manuals for Camera Accessories are available online for free. You can easily download all the documents as PDF.
Page 11
Indoor Pan/Tilt Head AW-PH400 AW-PH400 11 Parts and their function JY connector [Y] This is the output connector for the camera’s video signals. It is connected to the Y/VIDEO connector on the AW-RC400 cable compensation unit or monitor, etc. Use a BNC coaxial cable for the connecting cable. The AW-PB302 RGB card must be installed if the AW-E300, AW-E300A, AW-E600, AW-E800 or AW-E800A convertible camera is to be used. K1394 connector [1394] This is used for the control of the convertible camera and...
Page 12
Indoor Pan/Tilt Head AW-PH400 12 Installation(Be sure to ask your dealer to install the unit.) For a stand-alone installation For installation on the ceiling $Assembling the pan/tilt head When assembling the pan/tilt head, use the Allen key (provided) and sc\ rewdriver, and secure the head by tightening the screws firmly. After mounting the pan/tilt head, check there is no play in its \ installation. 1Attaching the camera mounting base Attach the camera mounting base to the rotary arm using the three...
Page 13
Indoor Pan/Tilt Head AW-PH400 AW-PH400 13 Installation(Be sure to ask your dealer to install the unit.) 3Mounting the tally lamp Connect the cable connector which is taped to the top of the pan/tilt he\ ad to the tally lamp connector. Mount the tally lamp on the top of the pan/tilt head using the two screw\ s provided. Mount the lamp while paying attention to the wire. If the tally lamp is not going to be used, insert the cable which is stu\ ck to the top of the pan/tilt head inside the pan/tilt head,...
Page 14
Indoor Pan/Tilt Head AW-PH400 14 Installation(Be sure to ask your dealer to install the unit.) $Setting the mounting direction switch Set the switch as follows when the unit is to be installed on the ceilin\ g. (This switch was set to the stand-alone installation position at the fa\ ctory.) 1 Remove the four screws, and gently remove the pedestal connector panel. \b Set switch S1 on the PCB inside the pan/tilt head as follows. For stand-alone installation: Set S1 to the rear position (T). (Factory...
Page 15
Indoor Pan/Tilt Head AW-PH400 AW-PH400 15 Installation(Be sure to ask your dealer to install the unit.) $Setting the PCB switches The switches on the CONNECTOR PCB will need to be set in accordance with\ the signals to be transmitted and the equipment to be connected to the pan/tilt head. (The switches are set to support analog/SDI at the factory.) ≥Analog/SDI support IP/IEEE switch: IEEE 422/IP switch: 422 ≥ Web card support IP/IEEE switch: IP 422/IP switch: IP ≥ IEEE1394 card support IP/IEEE switch:...
Page 16
Indoor Pan/Tilt Head AW-PH400 16 Installation(Be sure to ask your dealer to install the unit.) $Installing the pan/tilt head When installing the pan/tilt head, follow the instructions below careful\ ly. In order to prevent accidents resulting when the product becomes dislodg\ ed or falls down, be absolutely sure to proceed as instructed. Do not install the pan/tilt head on its side since its presc\ ribed operation and performance cannot be ensured. ≥After the pan/tilt head has been installed, mount the...
Page 17
Indoor Pan/Tilt Head AW-PH400 AW-PH400 17 $ Mounting the camera When mounting the camera on the pan/tilt head, be very careful to ensure\ that the camera does not fall off or fall down. 1 Mount the lens onto the convertible camera. (Before mounting a large le\ ns, consult with your dealer.) \b Insert the rubber piece between the camera and pan/tilt head, and mount \ the convertible camera after aligning it with the guide pins. Use a tool to tighten up the mounting screws so that they ar\ e securely...
Page 18
Indoor Pan/Tilt Head AW-PH400 18 Installation(Be sure to ask your dealer to install the unit.) $Attaching the wire The wire is not provided. Use one which is strong enough to bear the wei\ ght of the whole camera (camera + lens). When mounting the cameras with fan (AW-E655, AW-E750, AW-E800, AW-E800A\ ) 1 Use the wire mounting screw (M4!8 mm with flat washer and spring washer) to attach one end of the wire \ to the pan/tilt head’s arm. \b Mount the mounting spacer on the top panel of the camera. 3 Use...
Page 19
Indoor Pan/Tilt Head AW-PH400 AW-PH400 19 Replacing the consumable parts $Replacing the battery The battery has a service life of approximately 5 years. The unit stores the preset positions, limiters and other data in its mem\ ory. This data is retained even when the power is turne d off, but if the internal battery has reached the end of its service life\ , the data will be lost when the power is turned off. Replace a battery that has lost its charge with a new one. (Battery use\ d: CR2032 manganese...
Page 20
Indoor Pan/Tilt Head AW-PH400 20 Specifications Genlock input:BNC Black burst or composite video signal Prompter input (PROMPTER IN): BNC Through output to PROMPTER connector Prompter output (PROMPTER OUT): D-SUB 15-pin Camera video output VIDEO: BNC, 75-ohm output Y: BNC, 75-ohm output Pr/C: BNC, 75-ohm output Pb: BNC, 75-ohm output SDI: BNC Camera, pan/tilt head control: RJ45, RS-485, pan/tilt head control signal output RP/IP Connecting cable: 10BASE-T straight cable (equivalent to UTP category 5\ ),...
