Panasonic Kx-ta308, Kx-ta616 Advanced Hybrid System Operating Instructions

• Be sure the handset is on the cradle and the SP-PHONE button is off.
• After programming, return the MEMORY switch to the “SET” position or press the
PROGRAM button on the KX-T7300 series.
• See the Installation Manual, Section 3, “Direct Inward System Access (DISA)”.
• See the Installation Manual, Section 3, “Uniform Call Distribution (UCD)”.
• See the Installation Manual, Section 3, “Outgoing Message (OGM)”.
1.8 Operator / Manager Service Features
Operations1-93
Operator / Manager
/ DSS Console...

1.8 Operator / Manager Service Features
1-94Operations• This feature overrides the “Electronic Station Lockout” feature. If “Electronic Station
Lockout” has already been set by the extension user and this feature is set afterwards, the
extension user cannot cancel the lock. Only the operator or manager can cancel the lock.
• Extension passwords must be assigned to the operator and manager extensions beforehand.
• An extension user can make a call at the locked extension depending on system
programming....

1.8 Operator / Manager Service Features
Operations1-95
Operator / Manager
/ DSS Console Operations
Time (Day/Night/Lunch) Service Setting
This system supports the day, night and lunch modes. The system operation for
originating and receiving calls can be different in the day, night and lunch modes. Toll
restriction can be programmed to prevent unauthorized toll calls for each mode.
Changing Day, Night or Lunch mode in manual or automatic mode
PT
Lift the handset or press
SP-PHONE/MONITOR.For...

1.8 Operator / Manager Service Features
1-96Operations• The day/night/lunch mode can be changed either automatically at a predetermined time
(default: 9:00 a.m. for every day, 5:00 p.m. for every night) or manually at any time by
System Programming.
• Even if the automatic mode has been selected by System Programming, the operator or
manager can change the day, night and lunch modes manually.
• The following programs have separate day, night and lunch programming.
1) Delayed Ringing Assignment
2) Door...

1.8 Operator / Manager Service Features
Operations1-97
Operator / Manager
/ DSS Console Operations
• Be sure the handset is on the cradle and the SP-PHONE button is off.
• To program, set the MEMORY switch on the proprietary telephone to “PROGRAM” or
press the PROGRAM button on the KX-T7300 series.
• After programming, return the MEMORY switch to the “SET” position or press the
PROGRAM button on the KX-T7300 series.
• The extension number is displayed in the order of the jack number when you press the...

1.9 DSS Console Features
1-98OperationsPF buttons are provided with no default settings, while each DSS button has a default setting
as follows.
DSS 01–24: extension numbers 101–124
DSS 25–32: no default settings
To meet your various needs, DSS buttons can be changed to other function buttons.
Every DSS or PF button can be assigned to another extension number, telephone number or
feature number by Initial Settings.
• Be sure the handset is on the cradle and the SP-PHONE button is off.
• To program, set...

1.9 DSS Console Features
Operations1-99
Operator / Manager
/ DSS Console Operations
PT and DSS Console
Enter the desired
number.
phone no.
Press the desired DSS button (on the DSS
Console) and dial 2 (on the paired telephone),
or press the PF button (on the DSS Console).Press
AUTO DIAL/STORE.
AUTO DIAL
STORE
[DSS Console and Paired telephone] [Paired telephone] [Paired telephone]
Repeat these steps
to program numbers
for other DSS or PF
buttons.2
PF
+
One-Touch Dialing Assignment
You can assign a...

1.9 DSS Console Features
1-100Operations
PT and DSS Console
Dial 2.
2
Press the DSS or PF button
which you wish to cancel.Press AUTO DIAL/STORE.
AUTO DIAL
STORE
[DSS Console][Paired telephone]
[Paired telephone]
• The number is canceled.
To cancel after programming Day, Night and Lunch Buttons Assignment (Operator/Manager only)
You can assign a DSS button as the Day, Night or Lunch button. Simply pressing the assigned
button sets the day, night or lunch mode.
PT
For Day mode: Dial 4.
For Night mode:...

1.9 DSS Console Features
Operations1-101
Operator / Manager
/ DSS Console Operations
• DSS buttons can be changed to any of the following function buttons by Initial Settings.
a)AnotherDSS Button (Every DSS button can be assigned to another extension number.)
b) One-Touch Dialing Button
c) Day Button (Operator/Manager only)
d) Night Button (Operator/Manager only)
e) Lunch Button (Operator/Manager only)
f) Station Lock Button (Operator/Manager only)
• PF buttons can be changed to One-Touch Dialing...

1.9 DSS Console Features
1-102OperationsA call can be transferred to an extension using a DSS button.
Without Transfer
PT and DSS Console
Press the desired DSS button.
[DSS Console]
Press TRANSFER. [Paired Telephone]
During a conversation
TRANSFER
With Transfer
An outside call can be transferred to an extension using a one-touch operation.
The One-Touch Transfer function must be set by System Programming.
PT and DSS Console
Press the desired DSS button.
[DSS Console]
During a conversation
• The other...
