Page 1
Installation Manual Model No.KX-TGA20 Key Detector Thank you for purchasing a Panasonic product.Please read this installation manual before using the unit and save it f\ or future reference. This unit is an accessory for use with a Panasonic Digital Cordless Phon\ e. For more details, visit our Web site: http://panasonic.net/pcc/products/telephone/p/tga20/ For U.S.A. usersFor assistance, visit our Web site: http://www.panasonic.com/help for customers in the U.S.A. or Puerto Rico. For Canada usersFor...
Page 2
Introduction By registering the key detector to a Panasonic Digital Cordless Phone and attaching it to an easy-to-lose item in advance, you can locate and find the mislaid item to which the key detector is attached. Important: R Up to 4 key detectors can be registered to a Panasonic Digital Cordless Phone. R The key detector is not water-resistant. Exposing it to rain, water, or high humidity may cause it to malfunction. Note: R Eve n if the handset is out of the range of the base unit, you can use the...
Page 3
Registering a key detector to the unit Impo rtant: R For key detector supplied users: The supplied key detector has been pre-registered to the unit. R Do not install the battery until you activate the key detector registration using the handset. R After installing the battery in step 2, the registration mode will end within 30 seconds. 1 Handset: For key detector 1: MMENU N#6571 For key detector 2: MMENU N#6572 *1 For key detector 3: MMENU N#6573 *1 For key detector 4: MMENU N#6574 *1 *1 If you...
Page 4
Changing the key detector name 1 Han dset: For key detector 1: MMENU N#6561 For key detector 2: MMENU N#6562 *1 For key detector 3: MMENU N#6563 *1 For key detector 4: MMENU N#6564 *1 *1 If you have 2 or more key detectors. 2 Enter the desired name (10 characters max.). 3 MSAVE N a M OFF N Attaching the key detector to an easy-to-lose item Yo u can attach the key detector to items such as a car key or house key, etc. Locating and finding a mislaid item Yo u can locate and find the mislaid...
Page 5
Note: R Onl y one handset can search for a key detector. Other handsets cannot search at the same time. R The volume of the detection beeps and responding beeps cannot be changed. Range guidelines R The range of the handset and key detector under the best conditions is about 50 m (160 feet) indoors and about 200 m (650 feet) outdoors. Please note this range may be shorter when the key detector is near concrete barriers, etc. Operating tips R Pla c e the key detector away from the handset and...
Page 6
Note: R “Ba t tery dead ” may be displayed when there is radio interference or the key detector is out of range of the handset. Replacing the battery CR coin cell lithium battery performance (s u pplied battery) 6 months max. *1*1 Actual battery performance depends on usage and ambient environment. No t e: R We recommend you check the battery once a month and replace the battery regularly so that you can use the key detector anytime. R After installing the replacement battery, the key detector emits a...
Page 7
Liquid damage Problem Cause/solution Liquid or other form of m oi s ture has entered the key detector. R Remove the battery from the key detector and leave to dry for at least 3 days. After the key detector is completely dry, insert the battery. If the key detector does not work properly, contact an authorized service center. Caution: R To a void permanent damage, do not use a microwave oven to speed up the drying process. For your safety T o p revent severe injury and loss of life/property, read...
Page 8
R Do not replace a battery with wet hands. F o r U.S.A. users C R Coin Cell Lithium Battery Information: This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material - special handling may apply. See h t t p : / / w w w . d t s c . c a . g o v / h a z a r d o u s w a s t e / p e r c h l o r a t e FCC and other information (for U.S.A. users) Th i s device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not...
Page 9
Industry Canada Notices (for Canada users) NOTI CE: Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. RF Exposure Warning: R This Key Detector complies with IC radiation exposure limits set forth for an uncontrolled environment and portable operation, which does not require any minimum spacing be provided between antenna and person’s...
Page 10
Customer services (for U.S.A. users) 10InstallationTGA20(en-en)_1201_ver022.pdf 102012/12/01 19:54:55 Customer Services Directory (United States and Puerto Rico) TTY users (hearing or speech impaired users) can call 1-877-833-8855. TTY users (hearing or speech impaired users) can call 1-866-605-1277. Accessory Purchases (United States and Puerto Rico) Obtain Product Information and Operating Assistance; locate your nearest Dealer or Service Center; purchase Parts and Accessories; or make Customer...
