Panasonic Part For Network Functions And SD Memory Card Functions PT-L735NTE Manual

11
Wireless card
1
2
3
Insertion
• Turn off the power by putting the [MAIN POWER] switch to the   position.
• Forced insertion of the card in wrong direction may cause failure.
1
3
2
Removal
Turn off the power by putting the [MAIN POWER] switch to the   position.
Insertion and removal of wireless card and
SD Memory Card into / from the projector
Insert the card until
it is locked.
Attach the card
lock.
Secure the card
lock with the
supplied screw.
3 2
1
Remove the screw
of card lock.
Remove the card...

12
Insertion
Forcible insertion of the SD card in a wrong direction may cause a fault.
Removal
Be sure to confirm the access lamp is not blinking before card removal.
Removing the card while the lamp is blinking may destroy the data on the card.
Press the centre to
release the lock and take
out the card. Insert a card until it is
locked
SD Memory Card
Insertion and removal of wireless card and SD Memory Card into / from the projector
Access lamp

13
Removal
Quit Wireless Manager 3.0 if it is in use.
Left-click the [PC card] icon appearing on the task bar at the
right bottom of screen.
If the [PC card] icon is not appearing:
Go to [Start Menu]
→[Control Panel] and open [PC card].
Checkmark [Show control on the task bar] and press [OK].
Select [Panasonic Wireless LAN PC Card] and click [Stop].
Press [OK] and take out the wireless card.
3 2 1
Insertion
• Before inserting the wireless card, be sure to install the included Wireless
LAN Driver software...

14
Installation of software
note:
• Quit all software in action on Windows. Otherwise your installation may be
unsuccessful.
• Uninstall Wireless Manager 2.0 or Image Creator 1.0 if it has been installed
before this installation. (See page 70)
• If your PC runs on Windows XP/2000, the authority of Administrator is required
for this installation.
Wireless Manager 3.0:
This software can be used to transmit screen images and image files (JPEG and
PNG images) from the personal computer to the projector...

15
Installation of software
Notes :
• Installation of the Wireless LAN Driver in your personal computer must have
been completed before inserting the wireless card into the computer.
• If the card is accidentally inserted in the personal computer before installation of
the driver, the automatic hardware detection will find the card as an unidentified
device. If this is the case, do not remove the card, but carry out the following
steps with the card kept inserted before installation.
For Windows...

16
For Windows XP:
Click [Wireless LAN Driver] on the
screen of Procedure 1 on page 14.
This will activate the installer for wireless LAN
1
Click [Next].
A License Agreement message appears.2
Click [Yes].3
Specify the destination for saving
the utility and click [Next].
A logo authentication message appears.
4
Click [Continue].5
Click [Finish].6
Installation of software

17
Insert an optional wireless card
through a CF card adaptor.
(See page 13)
This will activate Found New Hardware Wizard.
7
Confirm that [Automatically install
the software] is checkmarked and
click [Next].
A logo text message appears.
8
Click [Continue].
A wizard completion message appears.9
Click [Finish].
A logo authentication message appears.10
Installation of software
When installation is complete, confirm as follows:
Go to [Start] →
[Programs] →
[Connect To] →
[Show all connections], and ensure...

18
For Windows 2000:
Click [Wireless LAN Driver] on the
screen of Procedure 1 on page 14.
This will activate the installer for wireless LAN
1
Click [Next].
A License Agreement message appears.2
Click [Yes].3
Specify the destination for saving
the utility and click [Next].
The software is downloaded, and [Digital signature
was not found] appears.
4
Click [Yes].
Following the instructions on the screen, go along
the steps.5
Click [Finish].
Installation is complete.6
Insert an optional wireless card
through...

19
For Windows 98SE/Me:
Click [Wireless LAN Driver] on the
screen of Procedure 1 on page 14.
This will activate the installer for wireless LAN
1
Click [Next].
A License Agreement message appears.2
Click [Yes].3
Specify the destination for saving
the utility and click [Next].
The software is downloaded.
4
Confirm that [Yes, I want to restart
my computer now.] is checkmarked
and click [Finish].
The personal computer will be rebooted.
5
Insert an optional wireless card
through a CF card adaptor.
(See page...

20
For Windows CE:
In the supplied CD-ROM, go to
[Wireless Card], open [Win CE] and
then click [setup.exe].
A screen for selection of folder setting language
appears.
1
Select [English], click [OK] and
click [Next].
A license window appears.
2
Click [Yes].
Following the instructions on the screen, go along
the steps.3
Click [Finish].
As [Unable to connect….] appears on the PDA
screen, click [OK].4
Insert the optional wireless card
(ET-CDWL2E) into PDA.5
Installation of software
Note:
Before starting...
