Panasonic Portable CD Player Sl Ct790 Operating Instructions

1
Portable CD player
Dear CustomerThank you for purchasing this product.
For optimum performance and safety,
please read these instructions carefully.
Supplied AccessoriesCheck the packing carton for these accessories.
Model No.SL-CT790
Before connecting, operating or adjusting this product, please read these
instructions completely. Please keep this manual for future reference.
Operating Instructions
The model number and serial number
of this product can be found on either
the back or the bottom of the...

Recharge the batteries before use.
Recharging procedure
1Slide [OPEN ] to open the lid.
2Open the battery lid and insert the
two rechargeable batteries.
Press to open in step 1.
3Connect the AC adaptor.
Recharging starts. The main units recharging lamp
(CHG) lights and the battery indicator on the remote
control scrolls.
When the rechargeable batteries are fully recharged,
the battery indicator disappears. (It takes approximately
5 hours to fully recharge the supplied rechargeable bat-
teries.)
4When...

3
Location of Controls
Portable CD player A
AOpen switch (OPEN)
BRecharging lamp (CHG)
CHeadphone jack (Ë)
DHeadphone volume control
buttons
(VOL s, r)
EPlay/pause button (1/;)
FStop/operation off button (∫)
GSkip/search buttons
(:, 9)
HHold switch (HOLD)
IDC IN jack
(KDC IN 4.5 V)
JBattery case terminal
(EXT BATT)
KRechargeable battery cover
Wired remote control B
ASkip/search buttons
(:, 9)
BVolume control (r, s)
CPlay/stop/operation off button
(1/∫)
DHold switch (HOLD 1)
EDisplay
FPlug
GEQ button...

4
Sequential Play Basic Play
12
3
4
5
PORTABLECDPLAYER
SL-CT790
OPEN
CHGV
O
L
HOLD
OPENEQMODEMEMORY
Remote control
HOLD
HOLD
HOLD
S-XBS
MODE MEMORY
Remote control
VOL
S-XBSVOL
MODE MEMORY
Remote control
L
R
Elapsed playing time of each track Track number in play Close the lid.
Plug type:
3.5 mm
(1/8 in.) stereo
Decrease Increase
Note on CD-R and CD-RWThis unit can play CD-DA format audio CD-R and
CD-RW that have been finalized§upon completion
of recording. It may not be able to play some CD-R
or CD-RW...

5RQT6154
Unit Remote control Display/referenceOperation
To pause play
To stop play
To turn off the
unit
Skipping
tracks
Searching
through tracks
Off mode
Stop mode
≥During program play (page 6), these buttons are
used to skip forward or backward through the pro-
grammed sequence of tracks.
≥You cannot skip to tracks that have been played in
random or random repeat play (page 6).
≥During program play, random play, random repeat
play or 1-track repeat play (page 6), search opera-
tion is limited to the...

Program play
Up to 24 tracks can be entered in the program.Preparation:Put unit in stop mode.
1Select the desired track.
2Register in sequence.(The indication “M” and the programmed se-
quence appear on the display.)
3Repeat steps 1 and 2 to program all
the desired tracks.
4
∫To program the same track in the se-
quence more than once
After step 2, press [MEMORY] (remote control) the de-
sired number of times.
∫If “'” is displayedNo more tracks may be programmed.∫To confirm the contents of the...

7
1. Damage requiring service—The unit should be serviced by qualified service per-
sonnel if:
1.(a) The AC power supply cord or AC adaptor has been damaged; or
1.(b) Objects or liquids have gotten into the unit; or
1.(c) The unit has been exposed to rain; or
1.(d) The unit does not operate normally or exhibits a marked change in perfor-
mance; or
1.(e) The unit has been dropped or the cabinet damaged.
2. Servicing—Do not attempt to service the unit beyond that described in these op-
erating...

8
Batteriesused
2 alkaline
batteries
2 rechargeablebatteries
2 rechargeable
and 2 alkaline
batteries
Specifications
Audio No. of channels: 2 (left and right, stereo)
Frequency
response: 20 to 20,000 Hz
(i0.5 dB to j10 dB)
DA converter: 1 bit, MASH
Headphone
output level: RMS max. 8 mWi8 mW/
16 ≠(adjustable)
PickupLight source: Semiconductor laser
Wavelength: 780 nm
GeneralOperational temperature
range: 0 eC–40 eC
(32 eF–104 eF)
Rechargeable temperature
range: 5 eC–40 eC
(41 eF–104 eF)
Power supply: DC...
