Panasonic Portable CD Player Sl Ct800 Operating Instructions

Dear CustomerThank you for purchasing this product.
Before connecting, operating or adjusting this
product, please read these instructions
completely. Please keep this manual for future
reference.
SL-CT800
PPC
Troubleshooting guide
Portable CD player
Operating Instructions
1
The model number and serial number of this
product can be found on either the back or
the bottom of the unit.
Please note them in the space provided
below and keep for future reference.
MODEL NUMBER
SERIAL NUMBER
RQT6648-PF0103KK0...

Audio (CD-DA)No. of channels: 2 (left and right, stereo)Frequency response: 20 to 20,000 Hz
(i0.5 dB toj10 dB)
DA converter: 1 bit, MASH
Headphone output level:
RMS max. 8 mW
i8 mW/
16≠(adjustable)
PickupLight source: Semiconductor laser
Wavelength: 780 nm
WMA/MP3Supported bit-rates:
WMA: 32 kbps to 192 kbps
(96 kbps is recommended)
MP3: 32 kbps to 320 kbps
(128 kbps is recommended)
Supported sampling frequency:
48 kHz/44.1 kHz/32 kHz
Maximum number of items
(sum of albums and tracks): 999
Maximum album...

ONLY FOR U.S.A.
3
Panasonic Consumer Electronics Company,
Division of Matsushita Electric Corporation of America
One Panasonic Way Secaucus, New Jersey 07094Panasonic Sales Company, Division of Matsushita Electric of Puerto Rico, Inc.
Ave. 65 de Infantería, Km. 9.5
San Gabriel Industrial Park, Carolina, Puerto Rico 00985
Panasonic Portable Audio Products Limited WarrantyLimited Warranty CoverageIf your product does not work properly because of a defect in materials or workmanship, Panasonic Consumer...

A
Location of controls/Connection to other equipment Turn off this unit and the other equipment  before connection.
4
∫To Battery case terminal
(EXT BATT)
Audio system
Adjust the volume level
on the audio system.
AC adaptorHousehold AC outletExternal battery case
Car power adaptor (SH-CDC9) (not included)
≥You can recharge the batteries
with this connection.
Some cannot
be connected.
Car audio
To CD or AUX
terminals
Audio cable (not included)
Car stereo cassette adaptor
(SH-CDM10A) (not included)
∫To...

2
3
4
234
1
1         0:01
OPEN
Power Supply
Playback
Open the lid and insert a CD.
Release HOLD.
Track number Elapsed playing
time of track
Press.
Adjust the volume.
(0 - 25)≥WMA/MP3 files take a
little longer to be read.
≥“WMA”/“MP3” lights on
the display during play.
5
Rechargeable batteries   Recharge before initial use.
Make sure the unit is off when recharging.
∫
The buttons flash while recharging and stop when finished (5 to 6 hours).∫You can also connect the AC adaptor directly to the DC IN...

ALBUM MODE
ALBUM3 –    10
1
4
3
2
M3   – – 01
Playing WMA/MP3
Starting play from an album (Album skip)
Press and hold until the
album you want appears.
Album numberNumber of tracks
Playing only the tracks in a selected album (Album mode)
Each time you press and hold [MODE]
No display
(canceled)
∫You can select another album with album skip.
∫You cannot turn album mode on during program play.
Changing the display
Each time you press and hold [$MEMO/%DISP]
Album
titleTrack
titleTrack number and
elapsed...
