Panasonic Portable CD Player Sl Mp35 Operating Instructions

1
Supplied AccessoriesCheck the packing carton for these accessories.
Model No. SL-MP35/
SL-MP36C
Before connecting, operating or adjusting this product, please read these
instructions completely. Please keep this manual for future reference.
Portable CD player
Operating Instructions
The model number and serial number
of this product can be found on either
the back or the bottom of the unit.
Please note them in the space provid-
ed below and keep for future refer-
ence.
MODEL NUMBERSERIAL NUMBER
Car...

2
Power Supply Preparations
Refer to the specifications (page 8) for information on operating times when using rechargeable batteries or dry cell batteries.
Using the AC adaptor
(not included)
Use only the recommended AC adaptor. Using other AC
adaptors can damage the unit.
Connect the AC adaptor.
2Connect the AC adaptor.(Refer to “Using the AC adaptor” for connection
instructions.) Recharging starts and the “              ”
charging indicator flashes on the display. When
the rechargeable batteries fully...

Sequential Play Basic Play
34 5
2HOLD
1
OPEN
OPEN
VOLUME
OPEN
/
TRACKALBUM
MP3M1RNDS-XBSL
R
HOLDH
O
L
D
Label must face upward.
Track number in play
Elapsed playing time of each track
3
Plug type:
3.5 mm (1/8 in.) stereo Close the lid.
Button Display/referenceOperation
To pause play
To stop play
To turn off the
unit
Skip forward/
backward
(skip function)
Rapid forward/
backward
(search function)
Off mode
Stop mode
For your reference:
“            ” indication
This indication appears for about 30 seconds...

4
Playing MP3 files
What is MP3?
A method of compressing audio, MPEG Audio Layer 3
(MP3) allows audio to be reduced to up to one tenth its
original size when a compression rate of 128 kbps is
used, without overtly hurting audio quality.
When creating MP3 files to play
on this unit
≥Disc formats:ISO9660 level 1 and level 2 (except for
extended formats)
≥Files:MP3 files with the suffix “.mp3” or “.MP3”
≥MP3 files may not be played in the order you recorded
them. Note the following if you want the files to play...

5
RQT6422
Button Display/referenceOperation
To pause play
To stop play
To turn off the
unit
Track skip
forward/
backward
Off mode
Stop mode
Sequential Play with MP3 files Basic Play
Follow steps 1–5.In step 2:Connect the stereo headphones or stereo earphones to the [Ë] jack. (Plug in firmly.)
In step 4:The time until play starts depends on the number of files on the disc. If the unit cannot read the disc cor-
rectly (it is scratched or dirty or the unit is bumped), some files may be left unread or the disc...

6
Other Play Methods with MP3 files
Track skip play
Plays from the selected track through to the last track
on the disc.
Plays from the selected track through to the last track in
the current album.
Preparation:Put unit in stop mode.
1Select the desired track.
2
Album skip play
You can skip album to album.
Plays from the first track of the selected album through
to the last track on the disc.
Plays from the first track of the selected album through
to the last track in the current album.
Press during play...

7
WARNING:TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PROD-
UCT DAMAGE, DO NOT EXPOSE THIS APPARATUS TO RAIN,
MOISTURE, DRIPPING OR SPLASHING AND THAT NO OBJECTS
FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON
THE APPARATUS.
CAUTION!THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
CAUTION:...

≥Remove the batteries if you do not intend to use the
unit for a long time.
≥Do not throw into fire, short-circuit, disassemble, or
subject to excessive heat.
≥Do not attempt to recharge dry cell batteries.
≥Do not allow metal objects to touch the battery termi-
nals as this may cause short-circuiting which is dan-
gerous.
≥When carrying batteries in a pocket or bag, ensure no
metal objects such as necklaces are placed together
with them. Contact with metal may cause short-circuit-
ing which can cause a...
