Panasonic Portable CD Player Sl Mp353j Operating Instructions

1
Model No. SL-MP353J
Portable CD player
Operating Instructions
OPENHOL
D
Dear customerThank you for purchasing this product.
For optimum performance and safety,
please read these instructions carefully.
Safety
1. Power source— Connect the unit to a power source
of the type described in these instructions or as
marked on the unit.
2. Polarization— The unit is equipped with a polarized
power plug where one blade is wider than the other.
This safety feature ensures that the plug fits into your
household AC...

2
Power Supply Preparations
Refer to the specifications (page 8) for information on operating times when using rechargeable batteries or dry cell batteries.
Using the AC adaptor
(not included)
Use only the recommended AC adaptor. Using other AC
adaptors can damage the unit.
To order the optional AC adaptorRP-AC46contact
1-800-332-5368 or web site (http://www.panasonic com).
Connect the AC adaptor.
2Connect the AC adaptor.(Refer to “Using the AC adaptor”.) Recharging
starts and the “         ” flashes on...

Sequential Play Basic Play
34 5
2 1
OPEN
OPEN
VOLUME
OPEN
/
TRACKALBUM
MP3M1RNDS-XBS
HOLDH
O
L
D
V
O
L
VOL
HOLDEQ
HOLD
HOLD
VOL
L
R
V
O
L
Label must face upward.
Track number in play
Elapsed playing time of each track
3
Plug type:
3.5 mm (1/8 in.) stereo Close the lid.
For your reference:
“            ” indication
This indication appears for about 30 seconds if you
press [1/;] (main unit) or [∫/1] (remote control)
when no disc is loaded or if the disc is not properly se-
cured.
“         ” indicationThis...

4
Playing MP3 files
What is MP3?
A method of compressing audio, MPEG Audio Layer 3
(MP3) allows audio to be reduced to up to one tenth its
original size when a compression rate of 128 kbps is
used, without overtly hurting audio quality.
When creating MP3 files to play
on this unit
≥Disc formats:ISO9660 level 1 and level 2 (except for
extended formats)
≥Files:MP3 files with the suffix “.mp3” or “.MP3”
≥MP3 files may not be played in the order you recorded
them. Note the following if you want the files to play...

5
RQT6548
Sequential Play with MP3 files Basic Play
TRACKALBUM
MP3M1RNDS-XBS
TRACKALBUM
MP3M1RNDS-XBS
TRACKALBUM
MP3M1RNDS-XBS
TRACKALBUM
MP3M1RNDS-XBS
5
OPEN
4
ALBUMMODE
DISPLAY
ALBUMALBUM
3 2 1
OPEN
OPENHOLDH
O
L
D
VOLUME
/V
O
L
VOL
HOLDEQ
HOLD
HOLD
VOL
L
R
V
O
L
Album number
Track number
Track number in play
Elapsed playing time of each track Label must face upward.
Plug type:
3.5 mm (1/8 in.) stereo
To switch between Disc and
Album mode
Plays all the tracks on the disc.
Plays all the tracks in the...

6
Other Play Methods with MP3 files
Track skip play
Plays from the selected track through to the last track
on the disc.
Plays from the selected track through to the last track in
the current album.
Preparation:Put unit in stop mode.
1Select a track.
2
Album skip play
You can skip album to album.
Plays from the first track of the selected album through
to the last track on the disc.
Plays from the first track of the selected album through
to the last track in the current album.
Press during play or stop...

7
WARNING:TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PROD-
UCT DAMAGE, DO NOT EXPOSE THIS APPARATUS TO RAIN,
MOISTURE, DRIPPING OR SPLASHING AND THAT NO OBJECTS
FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON
THE APPARATUS.
CAUTION!THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
CAUTION:...

≥Remove the batteries if you do not intend to use the
unit for a long time.
≥Do not throw into fire, short-circuit, disassemble, or
subject to excessive heat.
≥Do not attempt to recharge dry cell batteries.
≥Do not allow metal objects to touch the battery termi-
nals as this may cause short-circuiting which is dan-
gerous.
≥When carrying batteries in a pocket or bag, ensure no
metal objects such as necklaces are placed together
with them. Contact with metal may cause short-circuit-
ing which can cause a...
