Panasonic Portable CD Player Sl Mp50 Operating Instructions

1
Supplied AccessoriesCheck the packing carton for these accessories.
Model No.    SL-MP50
Before connecting, operating or adjusting this product, please read these
instructions completely. Please keep this manual for future reference.
Portable CD player
Operating Instructions
The model number and serial number
of this product can be found on either
the back or the bottom of the unit.
Please note them in the space provid-
ed below and keep for future refer-
ence.
MODEL NUMBERSERIAL NUMBER
Car adaptor . ....

Power Supply Preparations
Refer to the specifications (page 8) for information on operating times when using rechargeable batteries or dry-cell batteries.
Using the car adaptor
Be sure to use the supplied car adaptor specially de-
signed for this model.
(Refer to the separate installation instructions.)
The car adaptor can be used to recharge the unit’s bat-
teries while in the car.
Using the AC adaptor
(not included)
Connect the AC adaptor.
Using rechargeable batteries
(not included)
Obtain the optional...

Button Display/referenceOperation
To pause play
To stop play
To turn off the
unit
Skip forward/
backward
(skip function)
Rapid forward/
backward
(search function)
Off mode
Stop mode
Sequential Play Basic Play
Follow steps 1–6.In step 2:Connect the stereo headphones to the [Ë] jack. (Plug in firmly.)
≥Play stops automatically when all the tracks have been played.
≥If the unit has been connected to the car audio system, adjust the volume level between 4 and 6 on the unit, then
adjust the volume level on...

Other Play Methods
Skip play
The disc plays from the specified track through to the end, then
play stops automatically.
Preparation:Put unit in stop mode.
1
2
Select the desired track.
3
Program play
Up to 20 tracks can be entered in the programmed sequence.
Preparation:Put unit in stop mode.
1
2
Select the desired track.
3Register in sequence.
(The indication “M” and the programmed sequence appear
on the display.)
4Repeat steps 2 and 3 to program all
the desired tracks.
5
The letters such as Ain the...

5
RQT6080
Button Display/referenceOperation
To pause play
To stop play
To turn off the
unit
Track skip
forward/
backward
Off mode
Stop mode
Sequential Play with MP3 files Basic Play
Follow steps 1–6.In step 2:Connect the stereo headphones to the [Ë] jack. (Plug in firmly.)
In step 5:The time until play starts depends on the number of files on the disc. If the unit cannot read the disc cor-
rectly (it is scratched or dirty or the unit is bumped), some files may be left unread or the disc may not be
read at...

6
Other Play Methods with MP3 files
Track skip play
Plays from the selected track through to the last track in
the current album.
Plays from the selected track through to the last track
on the disc.
Preparation:Put unit in stop mode.
1
2
Select the desired track.
3
Album skip play
You can skip album to album.
Plays from the first track of the selected album through
to the last track in the current album.
Plays from the first track of the selected album through
to the last track on the disc.
Press during...

7
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PROD-
UCT DAMAGE, DO NOT EXPOSE THIS APPARATUS TO RAIN,
MOISTURE, DRIPPING OR SPLASHING AND THAT NO OBJECTS
FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON
THE APPARATUS.
CAUTION!THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
CAUTION:...

∫ CareTo prevent battery damage, electrolyte leakage and
short-circuiting, heed the following points.
≥Do not peel off the covering on batteries and do not
use if the covering has been peeled off.
≥Align the poles +and -correctly when inserting the
batteries.
≥Do not mix different types or of batteries or old and
new batteries.
≥Remove the batteries if you do not intend to use the
unit for a long time.
≥Do not throw into fire, short-circuit, disassemble, or
subject to excessive heat.
≥Do not attempt to...
