Panasonic Portable CD Player Sl Sw895 Operating Instructions

AC adaptor (RFEA415C-1S) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Stereo headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
(RFEV505P-S1S)
(RFEV708P-HS)
Hand grip (RGQT0006-K) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Car adaptor (SH-CDC12PEY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Car stereo cassette adaptor (SHCDM10B1PYK) . . ....

2
3Take off the attached rubber cap
and connect the AC adaptor.
Refer to “Using the AC adaptor” for connection in-
structions.
When recharging starts, the “H” charging indica-
tor flashes on the unit’s display.
4When recharging is complete, un-
plug the AC adaptor from the
household AC outlet and the DC IN
jack.
Note.
≥Rechargeable batteries have a service life of approxi-
mately 300 charge-discharge cycles. If the operating
time on one full charge becomes noticeably shorter
than it used to be, the...

3
Button Display/referenceOperation
To pause play
To stop play
To turn off the
unit
Skipping tracks
Searching
through tracks
Off mode
Stop mode
Sequential Play Basic Play
Follow steps 1–6.In step 3, connect the plug of the stereo headphones to the [Ë] jack, and plug in firmly until you hear the second click.
≥Play stops automatically when all the tracks have been played.
≥If the unit has been connected to the car audio system, adjust the volume level between 5 and 8 on the unit, then adjust the...

For your reference:≥If the play mode selector [MODE] is put in the
[RESUME] position, the all-track repeat function will
be activated automatically as soon as the unit is pow-
ered on.
≥If power is cut off near the end of a track (off mode),
playback may resume from the beginning of the next
track in some cases.
≥If the unit is powered off while a disc was playing and
then a new disc is inserted, play will begin from the
middle of the new disc because the unit remembers
the position where play stopped...

Using the unit with a car audio
system
SL-SW891C comes with a car adaptor and car stereo
cassette adaptor.
Items to be purchased
(SL-SW895/SL-SW890)
For connection to the car audio system:Car stereo cassette adaptor (SH-CDM10A)
For securing the unit and connecting the
power supply:
≥Car adaptor (SH-CDC9)
≥Car mounting kit (SH-CDF20)
Note.
It may not be possible to use the unit with some types of
car stereo owing to restrictions imposed by the con-
struction of the car stereo cassette adaptor.
For further...

6
ONLY FOR U.S.A.
For Product Information, Operating Assistance, Literature Request, Dealer Locations, and
all Customer Service inquiries please contact:
1-800-211-PANA (7262), Monday – Friday 9 am – 9 pm; Saturday – Sunday 9 am – 7 pm, EST.
Web Site: http://www.panasonic.com
You can purchase parts, accessories or
locate your  nearest servicenter by
visiting our Web Site.
Service in Puerto Rico
Matsushita Electric of Puerto Rico, Inc. Panasonic Sales Company/Factory Servicenter:
Ave. 65 de...

7
Product Service
Do not attempt to remove the cover(s) or repair the unit yourself. Refer servicing to
qualified personnel only.
Product information
For product service, product information or assistance with product operation, refer to
the servicenter directory.
WARNING:TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PROD-
UCT DAMAGE, DO NOT EXPOSE THIS APPLIANCE TO RAIN,
SPLASHING, DRIPPING OR MOISTURE.
CAUTION!THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES...

Audio (Anti-skip OFF)
No. of channels: 2 (left and right, stereo)
Frequency response: 20 to 20,000 Hz
(i0.5 dB, j1.5 dB)
Output voltage: 0.6 V (50 k≠)
S/N: More than 94 dB
§
Wow and flutter: Below measurable limit
DA converter: 1 bit, MASH
Headphones
output level: Max. 9 mWi9 mW/
16 ≠(adjustable)
PickupLight source: Semiconductor laser
Wavelength: 780 nm
GeneralOperational
temperature range: 0 eC–40 eC
(32 eF–104 eF)
Rechargeable
temperature range: 5 eC–40 eC
(41 eF–104 eF)
Power supply: DC 4.5 V...
