Panasonic Portable CD Player Sl Sx286j Operating Instructions

1
Supplied AccessoriesCheck the packing carton for these accessories.
Model No. SL-SX286J
Before connecting, operating or adjusting this product, please read these
instructions completely. Please keep this manual for future reference.
Portable CD player
Operating Instructions
The model number and serial number
of this product can be found on either
the back or the bottom of the unit.
Please note them in the space provid-
ed below and keep for future refer-
ence.
MODEL NUMBERSERIAL NUMBER
Precautions...

Removing batteriesPush up on the battery in
the direction indicated by
the arrow. Then lift it out.If the battery lid
comes loose
Slide the lid back into
place horizontally.
2
Power Supply Preparations
Refer to the specifications (page 8) for information on operating times when using rechargeable batteries or dry-cell batteries.
Using dry cell batteries
Insert two “AA” (LR6) alkaline batteries.
Note!≥The dry cell battteries should be changed when the
unit is off.
Using the AC adaptor
(not included)
Be...

3
Button Display/referenceOperation
To pause play
To stop play
To turn off the
unit
Skip forward/
backward
(skip function)
Rapid forward/
backward
(search function)
Off mode
Stop mode
Sequential Play Basic Play
Follow steps 1–5.In step 2:Connect the stereo headphones and wired remote control to the headphone jack [Ë]. (Plug in firmly.)
In step 5:The volume range is 0-25. Press and hold to change the volume successively. The volume changes when
pressed while the level is displayed. If any other display...

4
Other Play Methods
The letters such as Ain the various illustrations refer to the descriptions in the “Location of Controls” section (see below).
This system deals with skipping in a variety
of ways:
≥An anti-skip mechanism prevents skipping caused
when play speed changes due to swinging of the unit.
≥A recovery system immediately returns the laser pick-
up to its original position if it is knocked off the track by
a strong shock.
≥The 40-second anti-skip memory fills in interruptions
caused by bumps...

5
Using the Unit with Optional Accessories
L
R
Headphone jack(Ë)Other equipment
(White)
(Red)
Stereo connection
cable
(not included)CD or AUX
RQT5961
1Remove the screw from
the bracket at the rear
of the car mounting
base.
2
Replace the screw in the
lower hole of the bracket.
Bracket
Screwdriver
Using the Wired Remote Control
To start play
To stop play
To turn off
the unit
The remote control can be operated regardless of the
HOLD mode of the unit.
Preparation:Release the remote control from the HOLD...

6
For Product Information, Operating Assistance, Literature Request, Dealer Locations, and
all Customer Service inquiries please contact:
1-800-211-PANA (7262), Monday – Friday 9 am – 9 pm; Saturday – Sunday 9 am – 7 pm, EST.
Web Site: http://www.panasonic.com
You can purchase parts, accessories or
locate your  nearest servicenter by
visiting our Web Site.
Service in Puerto Rico
Matsushita Electric of Puerto Rico, Inc. Panasonic Sales Company/Factory Servicenter:
Ave. 65 de Infanteria, Km. 9.5, San...

7
WARNING:TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PROD-
UCT DAMAGE, DO NOT EXPOSE THIS APPLIANCE TO RAIN,
SPLASHING, DRIPPING OR MOISTURE.
CAUTION!THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
The product you have purchased is powered by a nickel-cadmium bat-
tery which is recyclable. Please...

8
Batteries used
2 alkaline batteries
2 optional rechargeable
batteries
(P-3GAVA/2B)
SpecificationsTroubleshooting Guide
Before requesting service, make the below checks. If you are in doubt about some of
the check points, or if the remedies indicated in the chart do not solve the problem,
contact the Panasonic Customer Call Center at 1-800-211-7262, or e-mail  con-
[email protected], or web site (http://www. panasonic.com).
Listening caution
Do not play your headphones or earphones at a high...
