Panasonic Projector Pt L6510u Specifications

Raising the Ceiling on Performance
PT-L6600U/UL
PT-
L6510U/UL
3600/4200 ANSI Lumens SXGA/XGA
LCD Projectors
1BriteOptic™ Dual Lamp System with four brightness settings to choose from
2Digital Cinema Reality for excellent moving images
3Easy setup and maintenance: Auto setup with digital keystone correction
BriteOptic™
Dual Lamp System
The difference is your image™
Presentation Products

Centered on Quality
Panasonic’s PT-L6600U/UL and
PT-L6510U/UL LCD projectors incorporate our
highly acclaimed BriteOptic™ Dual Lamp system,
which delivers high-definition images with superb
brightness.
Aided by extensive user input, we began
by making key improvements to the system
engine, then devised a symmetrical design that
places the lens directly in the units center, foreasier image positioning.  We also incorporated
the latest DSP technology to assure precise,
consistent performence.
The result:...

The PT-L6600UL and PT-L6510UL deliver the same superior
performance as the PT-L6600U and PT-L6510U, respective-
ly, but come with no lens. Combine them with an optional
lens to get the exact performance you need according to
usage and operating conditions.
Wide Variety: Choose the BriteOptic™Projector
that Best Meets Your Needs
PT-L6600U
SXGA Projector
• Ultrabright 3,600 ANSI lumens with 4-mode lamp operation
• BriteOptic™ technology and UHM™ lamps
• True SXGA (1,280 x 1,024), maximum UXGA (1,600 x...

Ultrahigh Brightness and Contrast
Panasonic’s advanced BriteOptic™ Dual Lamp
System delivers 3,600/4,200 ANSI lumens of
brightness and superior color reproducibility.
A corrective film is used to compensate for
phase shifts in the light incident to the LCD
panel, helping obtain a high contrast ratio. The
result is reproduction of crisp, clear, super-
bright images with outstanding depth.
Increased Reliability
These projectors have a long lamp life of
3,000 hours (at dual lamp operation in
standard...

Projection setting example
L:  Projection distance when mounted with the
ET-PKL6500. (Projection size is adjustable.)
H:  Height from upper/lower edge of projected
image to center of lens.
(Position of projected image can be easily
adjusted by using lens shift function.)
Edge of projected image
Projected
H
HL
PT-L6600U/L6510U
PT-L6600UL/L6510UL with the ET-LE050 fixed short-throw lens
PT-L6600UL/L6510UL with the ET-LE101 short-throw lens
Front view
Projection size(
W x H)LH
40 inches (813 x 610...

PT-L6600U PT-L6510U PT-L6600UL PT-L6510UL
100 – 240 V AC, 50/60 Hz
600 W (during standby mode with fan stopped: Max. 10 W)
5.0 A
NTSC/M-NTSC/PAL/PAL-M/PAL-N/SECAM
1.3˝ (diagonal) w/MLA     1.3˝ (diagonal)w/MLA 1.3˝ (diagonal) w/MLA 1.3˝ (diagonal) w/MLA
Transparent LCD panels (x 3)
Active matrix
1,398,784 786,432 1,398,784 786,432
(1,366 x 1,024) x 3 (1,024 x 768) x 3 (1,366 x 1,024) x 3 (1,024 x 768) x 3
Stripe
Power zoom/focus lens (1:1–1:1.3) (option)
F 1.7– 2.3, f 49.1– 63.8 mm (option)
DC type 220...
