Panasonic Pt D9610e Projector Specifications

High-Fidelity Projectors
•Ultra-high contrast ratio of 1,000:1
•Built-in multi-screen edge blending technology
•Network functions including remote control and status monitoring
•Abundant options for versatile system configurations
•Low-noise design
•One-touch auto setup
PT-D9610E
PAL/PAL-M/PAL-N/SECAM/NTSC/M-NTSC
PT-D9510E
Large Venue DLP™-Based Projectors

Sophisticated
High-Contrast,
Multi-Screen
Projection
The PT-D9610E and PT-D9510E debut
as the latest flagship models for Panasonic’s
large-venue DLP™-based projectors. These
exciting models inherit Panasonic’s brilliant
picture quality, advanced functions and easy
maintenance, and add a host of new
technologies, an extremely high contrast ratio,
and a new wired-maintenance function.
Panasonic’s edge blending function also makes
it easy to project high-quality images onto
multiple screens. The PT-D9610E...

High Brightness,
High Contrast
1,000:1 contrast ratio
Panasonic’s newly developed
optical system and dynamic lamp
control system with AI have
achieved a remarkable 1,000:1
contrast ratio. This combines with
a brightness of 12,000 (PT-
D9610E) / 10,000 (PT-D9510E)
ANSI lumens to deliver crisp, high-
resolution images in virtually any
viewing environment. Contrast can
be switched between Super, High
and Normal as conditions require.
Bright 12,000/10,000 ANSI
lumens
The PT-D9610E and PT-D9510E
feature a...

UFC for faithful moving
pictures
Each projector
is equipped with
Panasonic’s
Emmy Award-
winning
universal format
converter (UFC), a high-precision
digital filter that greatly improves
the moving image smoothness.
Projected images move smoothly
and naturally, and viewers cannot
perceive individual pixels.
Digital processing
The PT-D9610E and PT-D9510E
incorporate a host of Panasonic-
developed video-processing
technologies designed to ensure
superior reproduction of moving
pictures from a variety of...

device is unused. In multi-screen
projections with two projectors,
the DMD device works fully to
increase the image’s horizontal
resolution while maintaining the
maximum vertical resolution.
Built-in multi-screen
processor
The PT-D9610E and PT-D9510E
can project large, multi-screen
images without any additional
equipment. Up to 100 units (10 x
10) can be used at a time.
Maintenance
Network functions
The PT-D9610E and PT-D9510E
are network-ready, with interfaces
for 10Base-T and 100Base-TX
provided as...

D9610E-0109E10Mpdf
Weights and dimensions shown are approximate. Specifications subject to change without notice.
This product may be subject to export control regulations. VGA and XGA are trademarks of
International Business Machines Corporation. SVGA is a registered trademark of the Video
Electronics Standards Association. Windows is a registered trademark of Microsoft Corporation. All
other trademarks are the property of the various trademark owners. Projection images simulated.
Panasonic is the...
