Panasonic Pt Ds20k Projector Specifications

 PT-DZ21K
 PT-DS20K
 PT-DW17K
3-Chip DLP™ Projectors
PT-DZ21K Series
20,000 lm* of Brightness and
Rich Features from an
Extraordinarily Compact Body
* 17,000  lm for the PT-DW17K.

Splendid Images from a
Compact Body
Incredible  20,000  lm*1 of Brightness
Panasonic’s unique quad-lamp system, with its
new high-power UHM
lamps, has helped to
make the body ex
tremely compact while
providing an astound-
ing 20,000 lm*1 of
brightness.
Dynamic  Iris  for  a  High  10,000:1*3  Contrast
Ratio
Panasonic’s Dynamic Iris
uses a scene-linking aper-
ture mechanism to achieve
a remarkable 10,000:1*3
contrast without lowering its
high brightness. This helps
to reproduce deeper,...

12,000  hours  reduces
hassle,  and  the  environ-
mental  design  lets  you
wash  the  filter  with  water
and  reuse  it.*7
System and Installation Flexibil-
ity with Diverse Functions
Flexible  Installation
The  wide  adjustment
range  of  the  powered
horizontal/vertical  lens
shift  function  can  be  easi-
ly  adjusted  with  the
remote  control.  The  unit
can  also  be  rotated  360°
vertically*8,  to  accommodate  various  installation
conditions.  The  lens-centered  design...

Te r m i n a l s
1 Remote  1  input/output2 Remote  2  input3 Serial  input/output4 SDI  1  input  (PT-DZ21K/DS20K  only)5 SDI  2  input  (PT-DZ21K/DS20K  only)6 HDMI  input7 RGB  1  input8 DVI-D  input9 RGB  2  input10 Video  input11 3D  sync  1  input/output  (PT-DZ21K/DS20K  only)12 3D  sync  2  output (PT-DZ21K/DS20K  only)13 LAN  connector
1
45613912108117
23
Optional Accessories
ET-D75LE6 Zoom  lens
ET-UK20 Upgrade  Kit( Geometr y  Manager  Pro included)
ET-SFR510 Smoke  cut  filter
ET-EMF510...

fH: 15.75 kHz, fV: 60 Hz [480i (525i)]fH: 31.50 kHz, fV: 60 Hz [480p (525p)]fH: 15.63 kHz, fV: 50 Hz [576i (625i)]fH: 31.25 kHz, fV: 50 Hz [576p (625p)]fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]fH: 33.75 kHz, fV: 60 Hz [1035/60i]fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]fH: 28.13 kHz, fV: 25 Hz [1080/25p]
fH: 27.00 kHz, fV: 24 Hz [1080/24p]fH: 27.00 kHz, fV: 48 Hz [1080/24sF]fH: 33.75 kHz, fV: 30 Hz [1080/30p]fH: 67.50 kHz,...

Weights  and  dimensions  shown  are  approximate.  Specifications  and  appearance  are  subject  to change  without  notice.  Product  availability  differs  depending  on  region  and  country.  This  product may be subject to export control regulations. DLP, DLP logo and DLP Medallion logo are trademarks or  registered  trademarks  of Texas  Instruments. The  projection  distances  and  throw  ratios  given  in this leaflet are for use only as guidelines. For more detailed information, please consult...
