Panasonic Pt F300u Projector Specifications

Designed for Durability
and
Installation Flexibility
PT-FW300NTU
PT-FW300U
PT-F300NTU
PT-F300U
LCD Projectors
PT-F300Series

High Durability for
Long-Lasting Brightness
New Inorganic Materials Add Durability to
the Optical Block
The F300 Series projectors’
optical block maintains a high
level of performance over
time, due to the use of inor-
ganic materials in the LCD
panels and polarizers. It also
makes them the logical choice
for a truly dependable LCD
projector system.
Auto Cleaning Filter to Minimize Maintenance
Panasonic’s proprietary Auto
Cleaning Filter (ACF) uses a
highly efficient electrostatic
filter called the...

2
PT-FW300NTU
Choose the One that Meets Your Needs
Panasonic PT-F300 Series
projectors boast superior
installation flexibility and
easy maintenance, making
them the ideal choice for
business or educational use.
WXGA3,500 lm
PT-F300NTU
XGA4,000 lm
PT-FW300U
WXGA3,500 lm
PT-F300U
XGA4,000 lm
Side by SideSide by Side
Looking to Replace Your Projectors?
Full of Features for Smooth Replacements
PT-F300 Series projectors make ideal replacements in existing systems. The 2x zoom lens and hor-
izontal/vertical...

Brightness of 4,000/3,500 lumens
A high-performance optical system combines with a high-efficiency 250 W
UHM lamp to deliver a high brightness of 4,000 lumens (PT-F300NTU
and PT-F300U) or 3,500 lumens (PT-FW300NTU and PT-FW300U). All
models deliver crisp, bright images that are easy for the audience to see.
Daylight View 5 Gives Better Color Perception for Easy
Viewing in Various Lighting Conditions
The PT-F300 Series features Panasonic’s Daylight
View 5 technology. Remarkable detail is provided
and...

Direct Power Off
You can turn off the room’s main power without waiting for the projector to
cool down, because the fan keeps operating until the lamp returns to room
temperature.
Easy Lamp Replacement
For easier maintenance, you can replace the lamp from the rear. The
lamp is easily replaced even after the projector is installed on the ceiling.
Furthermore, Panasonic PT-F300 Series projectors use the same lamp as
the Panasonic PT-F100/F200 Series projectors, for efficient lamp pur-
chase planning.
Easy...

NOTES ON USE
• The projector uses a high-voltage mercury lamp that contains high internal pressure.
This lamp may break, emitting a large sound, or fail to illuminate, due to impact or
extended use. The length of time that it takes for the lamp to break or fail to illumi-
nate varies greatly depending on individual lamp characteristics and usage conditions.
• The brightness of the lamp will gradually decrease with use.
• The projector includes consumable parts. The frequency of replacement for the lamp...
