Sony LCD TV KDL-55EX645 User Manual

61
Using the Menus
 You can turn on Closed Captions (CC) options (On, Off or On when Muting) by pressing the
CC button on the remote control. Closed
Captions
(CC)Allows you to select from several closed caption modes (for programs that are
broadcast with closed captioning).
CC Display On Closed Captions (CC) is turned on.
Off Closed Captions (CC) is turned off.
On when
MutingClosed Captions (CC) is turned on when the TV
is muted.
Analog CCAllows you to select basic analog (EIA-608) closed caption...

62
 Favorite channel list will be cleared each time you run the Initial Setup.
 You can assign following labels for each input:
–, Cable, Satellite, VCR, DVD/BD, Home Theater, Game, Camcorder, Digital Camera, PC,
Edit (except PC IN)
–, Edit (for PC IN)
–” indicates that no labels are assigned.
 If you select Edit, you can edit video labels. Follow the same steps for Edit Channel Labels on
page 55.
OptionDescription
Info BannerSelect Small to display minimal channel and program title or select Large to...

63
Using the Menus
OptionDescription
HDMI
SettingsCommunicates with equipment compatible with the Control for HDMI function.
Control for
HDMILinks the operations of the TV and the equipment.
For specific Sony equipment compatible with Control for HDMI,
this setting is applied automatically to the connected equipment
when set to On.
Device Auto
Power OffSelect On to have your connected equipment with Control for
HDMI function power off automatically when the TV is turned off.
Select Off to disable...

64
Automatic
Software
DownloadSelect On to download the software automatically. Select Off to disable it.
Product
SupportContact SonySony contact information is available on this screen for your
convenience. TV specific information such as Model Name,
Serial Number, Software Version and downloadable ratings (if
available from the TV) are displayed here.
Signal
DiagnosticsPress to display the diagnostics information for the current
signal.
Initialize
Personal
InformationYou can erase your...

65
Using the Menus
Using the Eco Settings
OptionDescription
ResetResets the current Eco settings to the default values.
Power SavingSelect from Off, Low, High, Picture Off to adjust your TV’s power consumption.
By selecting the High option, you will reduce the power consumption more than
the other available settings.
While Picture Off is set, pressing VOL +/– or MUTING buttons will not disable this
function. Press other buttons to disable it.
Idle TV
StandbySelect to automatically power off the TV...

66
Other Information
PC Input Signal Reference Chart for
PC and HDMI IN
After connecting the PC to the TV, set the output signal from the PC according to the
chart below.
* The 1080p timing when applied to the HDMI input will be treated as a video timing and not PC
timing. This affects Picture settings and Wide Mode settings. To view PC content set Scene
Select to Graphics, Wide Mode to Full, and Display Area to Full Pixel.
 This TV’s PC input does not support Sync on Green or Composite Sync.
 This...

67
Other Information
Using a Wall-Mount Bracket
Your TV can be mounted on a wall using a Wall-Mount Bracket (not supplied) out of the
box as packaged. Some larger size TV may require removing the Table-Top Stand; refer
to the instructions provided with the TV.
Prepare the TV for the Wall-Mount Bracket before making cable connections.
For product protection and safety reasons, Sony strongly recommends that you
use the Wall-Mount Bracket designed for your TV and the installation should be
performed by...

68
Installing the Wall-Mount Bracket
xTo Customers
Your TV can be wall-mounted using SU-WL500 Wall-Mount Bracket (sold separately).
Please provide this installation information as well as the instruction supplied with SU-
WL500 Wall-Mount Bracket to your installer.
xTo Sony Dealers and Licensed Contractors
To avoid injury and property damage, read these instructions carefully. Periodic
inspection and maintenance is highly recommended to ensure that TV is securely
mounted.
xNote when installing
When...

69
Other Information
For SU-WL500
Step 1: Check the parts required for the installation
Open the Wall-Mount Bracket package and check the contents for all required parts
along with the Instructions.
Step 2: Decide on the installation location
Decide where you want to install your TV. Refer to the TV installation dimensions table.
Refer to the Instructions for SU-WL500.
xDimension Table
Figures in the above table may differ slightly depending on the installation.
CAUTION
The wall that the TV will be...

70
Step 3: Install the Base Bracket on the wall
Refer to the Instructions for SU-WL500.
Step 4: Prepare the TV for wall mount installation
Follow the steps below to prepare for installing the TV.
1Disconnect all the cables from the TV.
2Detach the Table-Top Stand from the TV.
Remove the screws guided by the arrow marks and of the TV.
Do not remove any other screws from the TV.
3Place the TV with its screen facing down on a level and stable surface covered with
a thick and soft cloth.
 Before attaching...
