Sony Vegas 6 Manual

CHP. 7USING AUTOMATION
167
Automating 5.1 surround projects
5.1 surround is available only in the full version of Vegas software.
In a 5.1 surround project, you can automate the center channel’s volume and surround panning using
keyframes. For more information, see Working with 5.1 Surround on page 209.
Automation recording modes
Automation recording allows you to edit envelope and keyframe settings by using the controls in the Vegas
interface. When combined with a control surface, you can create fades...

168
USING AUTOMATIONCHP. 7
4.Click to position the cursor in the timeline, and click the Play button  to start playback.
5.Adjust the control that corresponds to the envelope point or keyframe you want to adjust.
During playback, adjusting a control will create envelope points or keyframes at the cursor position. As
long as youre adjusting the control, new envelope points/keyframes will be created for each change of the
play cursors position.
6.Click Stop  to end playback and stop recording...

CHP. 7USING AUTOMATION
169
Editing individual envelope points or keyframes
Editing individual envelope points or keyframes gives you fine control over your recorded settings.
1.Click the Automation Settings button  on the track you want to edit and select Show Automation
Controls
.
2.Click the Automation Settings button  and choose Automation Write (Touch) or Automation Write (Latch)
from the menu.
3.Select the parameter you want to edit:
 For a track envelope, select the envelope tool  and click the...

170
USING AUTOMATIONCHP. 7

8
CHP. 8WORKING WITH EVENTS
CHAPTER171
Working with Events
Events are windows into media files in a project and are the most basic unit of editing in Vegas® software.
Media files that are inserted into the timeline are automatically contained within an event. Trimming and
editing an event does not affect the source media file in any way.
Setting event switches
Event switches are important functions that are used to determine the basic behavior of events. You can set
switches for a single event or...

172
WORKING WITH EVENTSCHP. 8
For video events, turning off the Loop switch makes the last frame repeat for the duration of the event
beyond its original length, creating a freeze frame effect (as in the middle example below). The Loop switch
is enabled for the event in the last example below
.
Invert phase (audio only)
This feature is available only in the full version of Vegas software.
This switch inverts the audio event at its baseline, in effect reversing its polarity. Inverting an event, while...

CHP. 8WORKING WITH EVENTS
173
3.Click Re-calculate to normalize the event again.
Tip: You can set the maximum decibel level used to calculate
the event during normalization. For more information, see
Audio tab on page 333.
Maintain aspect ratio (video only)
Video and image files of various sizes and formats can be included in a single project. The project itself may
have a different frame size aspect ratio from the source media files. This is not a problem, but you must
specify how these differences...

174
WORKING WITH EVENTSCHP. 8
Accessing event properties
The properties of an event are automatically determined based on the properties of the source media file. In
addition to the event switches (mute, loop, etc.) described in the previous section, event properties include
playback and undersample rates for video and pitch shifting for audio.
1.Right-click an event to display a shortcut menu.
2.From the shortcut menu, choose Properties. The Properties dialog appears.
The first tab in the dialog,...

CHP. 8WORKING WITH EVENTS
175
Copying and pasting event attributes
You’ve set up one event exactly the way you want it, and now you want to apply the same attributes to
another event. A quick way to copy the attributes of one event and paste them onto another is provided.
You can copy and paste multiple event attributes, including:
 Properties (pg. 174), including audio pitch shift (pg. 127) and video playback rate (pg. 129)
 Switches (pg. 171)
 Video event plug-ins (pg. 241)
 Cropping (pg. 223)...

176
WORKING WITH EVENTSCHP. 8
Setting an audio event’s volume
When you place the mouse pointer at the top of the event, the pointer changes to a hand cursor () that you
can use to lower the event’s overall volume.
1.Place the mouse pointer at the top of the event.
2.When you see the envelope cursor (), drag the volume envelope
to the desired level. As you drag, the event’s decibel level is
displayed.
Note: When you have multiple events selected, the gain of
all selected events is adjusted...
