CHP. 14USING VIDEO FX, COMPOSITING, AND MASKS
257
In the next example, clicking the Make Compositing Parent button () on track 3 forces the track below (at
the same compositing level) to be rendered in 3D and composited as a 2D image.
Track 4 (green-and-gray checkerboard) now has the appearance of depth—the checkerboard tapers to a
vanishing point—but is inserted in the composited output as a 2D image at a depth of zero on the Z axis.
Track 2 is still rotated in 3D space.
In the next example, clicking...

258
USING VIDEO FX, COMPOSITING, AND MASKSCHP. 14
Creating image masks
You can use media generated by Vegas software to create simple masks. You can also create masks from just
about any image file.
1.Create an image of a solid white circle on a black background in any paint program. This will be the mask.
2.Add the mask image file as an event into the top-most track on the timeline.
3.Insert a video event just below the mask track. This is the background video behind the mask and is the
event that is...

CHP. 14USING VIDEO FX, COMPOSITING, AND MASKS
259
Creating video masks
You can also use video files to create masks, although the process can be more complicated than using an
image as a mask. The key to any mask is contrast. You can increase the difference between the light and dark
areas of a video file using video effects plug-ins.
1.Insert the video that you want to use as a mask into a video track.
2.Drag a Black and White plug-in from the Video FX window to the event to remove the color. For more...

260
USING VIDEO FX, COMPOSITING, AND MASKSCHP. 14
Bézier masks
This feature is available only in the full version of Vegas software.
You can use the Event Pan/Crop dialog to create masks using Bézier curves.
Use the controls in the Path heading on the left side of the Event Pan/Crop dialog to create masks using
Bézier curves. Each event can contain multiple Bézier masks.
When you use a single setting for the duration of an event, you are masking the contents of the event. You
can add keyframes to...

CHP. 14USING VIDEO FX, COMPOSITING, AND MASKS
261
Editing the path
Use the tools on the left edge of the Event Pan/Crop window to edit your mask.
IconTo o lDescription
Normal EditUse to select and edit control points and tangents.
Click a point to select it, or drag to move the point.
Hold  while clicking to select/deselect multiple points.
Hold  and click a segment to select all points on the path. The pointer is displayed as a .
Hold + while clicking an anchor point to invert the selection state of...

262
USING VIDEO FX, COMPOSITING, AND MASKSCHP. 14
Setting path options
1.Select a path with the Normal Edit tool .
2.Expand the Path heading on the left side of the window to set options for the selected path.
3.Choose a setting from the Mode drop-down list to choose the selected paths masking behavior.
Positive — The area inside the path is visible in your video output.
Negative — The area outside the path is visible in your video output. The area inside the path is
transparent.
Disabled — The path...

CHP. 14USING VIDEO FX, COMPOSITING, AND MASKS
263
Using the Mask Generator
The Mask Generator is a plug-in that controls the transparency of events to be used as masks when you use
events that are not grayscale. Apply the plug-in to an event (or a track) in the same way as any other plug-
in: just drag-and-drop. The Mask Generator plug-in can be found in the Video FX
 window (from the View
menu, choose
Video FX).
How the Mask Generator works
The following illustration demonstrates some of the effects...

264
USING VIDEO FX, COMPOSITING, AND MASKSCHP. 14
The top-right example uses luminance to determine the transparency in the mask. The white area is
completely transparent. Since white is made up of 100% values of red, green, and blue (255,255, and 255),
those three colors are all 33% transparent as well. In the lower-right example, blue is the selected
transparent index. The blue area is 100% transparent and so are all areas that have a value of 255 for blue
(0,0,255), including white (255,255,255)....

CHP. 14USING VIDEO FX, COMPOSITING, AND MASKS
265
6.In the Video Event FX window, click the Eyedropper
button (
). The cursor changes to an eyedropper icon.
7.Draw (click and drag) a small rectangular selection area
around the color(s) to key out. Although you can select
the color range from just about anywhere, the Video
Preview window is the best location.
Note: Other effects that can change the color of the event
should be bypassed when using the Eyedropper tool.
8.Click the Split Screen View...

266
