Stiga Lawn Mower 8211 0223 06 Multiclip Operators Manual
Here you can view all the pages of manual Stiga Lawn Mower 8211 0223 06 Multiclip Operators Manual . The Stiga manuals for Lawn Mower are available online for free. You can easily download all the documents as PDF.
Page 1
DEUTSCHD 8211-0223-06 Multiclip
Page 2
SVENSKAS ADD FULL FULL ADD MAX MIN MAX MIN 12 34 2. 8. Tecumseh7. Honda 6. Briggs & Stratton5. 3. PRO 464. PRO 46 A 1.
Page 3
SVENSKA S 11. Tecumseh 3x 14. 12. Honda 15. Briggs & Stratton13. Tecumseh A D C E 3x 10. Briggs & Stratton9. STOP G B
Page 4
SVENSKAS 18. 40 Nm 0,75 mm 17. Briggs & Stratton : 0,76 mm Tecumseh: 0,6 mm Honda: 0,7-0,8 mm 16. Honda
Page 5
ENGLISHGB SYMBOLS The following symbols are displayed on the ma- chine in order to remind you about the safety pre- cautions and attention necessary when using the machine. The symbols mean: Warning! Read the Instruction Book and Safety Manual before using the machine. Warning! Keep spectators away. Beware of objects being flung out. Warning! Do not put hands or feet under the cover of the machine when it is run- ning. Warning! Before starting any repair work, remove the spark plug cable from the spark...
Page 6
ENGLISHGB Tecumseh:Stand the lawnmower on a level sur- face. Clean the area round the oil plug, then re- move the plug (fig. 8). If the oil is not level with the edge of the hole, carefully pour in clean oil. Re- place the oil plug. FILL UP THE PETROL TANK Fill with petrol before starting the mo- tor. Never remove the filler cap or fill with petrol while the motor is running or still warm. Never fill the fuel tank completely full but allow a little room for the petrol to expand. Always use pure unleaded...
Page 7
ENGLISHGB If the start/stop loop no longer works, stop the engine by removing the lead from the spark plug. Immediately take the lawn mower to an authorised work- shop for repairs. MOWING TIPS Before mowing the lawn, take care to remove any stones toys and other hard objects. A machine with MULCHER system cuts the grass, chops it finely and then blows it down in the lawn. The grass clippings need not to be collected. The following rules should be observed to give best MULCHER effect: 1. Use a high engine...
Page 8
ENGLISHGB Honda:Take off the cover then remove the filter (Fig. 16). Check the filter carefully for holes or other damage. A broken or damaged filter must be replaced. To remove dirt, tap the filter several times against a hard surface, or blow compressed air through the filter from the back. Try not to clean the filter by brushing, as this will force the dirt into the fibres. A very dirty filter should be replaced. Clean the air filter after every 25 hours of use, or once every season; more often if the...
