Stiga Lawn Mower 8211-3453-02 Silent 40 Batt Instruction Manual
Here you can view all the pages of manual Stiga Lawn Mower 8211-3453-02 Silent 40 Batt Instruction Manual. The Stiga manuals for Lawn Mower are available online for free. You can easily download all the documents as PDF.
Page 1
DEUTSCHD Silent 40 Batt 8211-3453-02
Page 2
4 SVENSKA S 33 11R MOPR M LL 22 2. 2 2 3. 4 54 I JK I J K N 1. 230 V
Page 3
5 SVENSKAS 8.9. 7. 4. ABC 5. 6. 36 mm 19 mm 10.11 .
Page 4
6 ENGLISHGB SYMBOLS The following symbols are displayed on the ma- chine in order to remind you about the safety pre- cautions and attention necessary when using the machine. The symbols mean: Warning! Read the Instruction Book and Safety Manual before using the machine. Warning! Keep spectators away. Beware of objects being flung out. Warning! Take out the safety key before any type of maintenance is carried out. Warning! Do not put hands or feet under the cover of the machine when it is running....
Page 5
7 ENGLISHGB The charger always feels warm to touch, during the first hours of charging. CHARGING BEFORE WINTER STORAGE The battery should always be stored ful- ly charged. 1. Take the battery out of the mower. 2. Carefully wipe off the battery. 3. Store the battery outside of the mower in adry and coolplace. USING THE MOWER CUTTING HEIGHT (fig. 4) Individual wheel height adjustment. Note! The same cutting height should be set on all four wheels. STARTING/STOPPING THE MOWER Keep hands and feet well away...
Page 6
8 ENGLISHGB charge the battery once it has cooled down (after about 30 minutes). Do not use the mower again until the battery is fully charged. Important:do not allow the battery power to com- pletely run down as this may damage the battery and shorten its operational life. MOWING TIPS For best cutting results and to ensure that the bat- tery lasts as long as possible, the following rules should be followed: Drive the mower at a slow and even pace Try to avoid excessive starting and stopping, as this...
Page 7
9 ENGLISHGB If the mower still doesnt work, despite measures taken according to this table, contact an authorised service dealer.Problem Possible causes 1. Mower does not start when safety key is inserted and the safety han- dle is pressed in A. Check to make sure the safety key has been properly inserted and that the engine protection is pressed in. B. Remove safety key, turn mower over on side and check that blade is not obstructed. C. Is battery fully charged? Plug in charger and check lamps. 2. Mower...
