Page 1
DEUTSCHD 8211-3503-01 102 M
Page 2
2 O (x4) M (x4) N (x4) P (x4) Q(x4)J(x2) S (x4) U (x2) T (x2)X(x2 ) V(x2) Y(x 2) O M N P Q J T U S R S 1. 2.
Page 3
3 B C D C F G 3. 4. 5. 6.7. 8. 9. 10.
Page 4
4 Z X Y V W 11 . 15. 16. 12. 13. 17. 14. 18.
Page 5
5
Page 6
6 ENGLISHGB SYMBOLS The following symbols are displayed on the ma- chine in order to remind you about the safety pre- cautions and attention necessary when using the machine. The symbols mean: Wa r n i n g ! Read the instruction book and safety man- ual before using the machine. Wa r n i n g ! Do not put hands or feet under the mower deck casing when the machine is running. Wa r n i n g ! Beware of objects being flung out. Keep spectators away. Wa r n i n g ! Before starting any repair work, remove the...
Page 7
7 ENGLISHGB 4. Tighten the screws. USE MOWING HEIGHT The mower deck has 17 fixed mowing heights, from30mmto80mm. N.B.Thestatedmowingheightsapplywhenthe machine is standing on firm ground. Before driving up onto a ramp, trailer or the like, first adjust the mowing height to the lowest position. Otherwise there is a risk that the mower deck will be damaged when the mower deck stops strikes the underside of the base machine. MOWING HINTS For the best Multiclip effect follow this advice: - mow regularly. -...
Page 8
8 ENGLISHGB Always check the position of the blades after changing the drive belt or adjusting the tension. CHANGING BLADES Use protective gloves to prevent cuts when changing blades/blade tips. Make sure the blades are always sharp. This gives the best mowing results. Always check the blades after an impact. If the blade system has been damaged the defective parts must be changed. Always use original spare parts. Using non-original spare parts can result in the risk of damage even if they fit in the...
