Stiga Lawn Mower COLLECTOR 30 Inch Manual
Here you can view all the pages of manual Stiga Lawn Mower COLLECTOR 30 Inch Manual. The Stiga manuals for Lawn Mower are available online for free. You can easily download all the documents as PDF.
Page 1
STIGA COLLECTOR 30 8211-1227-02 B INSTRUCTIONS FOR USE
Page 2
SVENSKA S 1. 2. 3. 4.
Page 3
SVENSKAS 5. 6. 7.8. 9. 10. 11. 12.
Page 4
SVENSKA S 13. 14. 15.16. 17.18. 19.
Page 5
ENGLISHGB SAFETY INSTRUCTIONS 1. Never allow anyone to use the collector without correct instructions. 2. Do not allow children to use the collector. 3. Do not operate the machine too close to naked flames, as the hopper bag and the brushes are highly flammable. 4. Do not attempt to remove objects that have be- come caught up in the brush (e.g. pieces of string) while the brush is rotating. 5. Move at reduced speed over uneven surfaces and on slopes to ensure you do not lose control or the machine...
Page 6
ENGLISHGB 8. Install the height setting strut (8) on the angle (W). Position the spacer (K) on the screw (E). Insert the screw with the spacer through the hole in the height setting strut and into the hole in the angle. Lock in place with the locking washer (J) and the nut (H). 9. Attach the other end of the height setting strut (8) to the height setting arm (7). Position the groove in the height setting strut opposite the square hole in the arm. 10.Screw into place with a carriage bolt (D), a...
Page 7
ENGLISHGB Emptying The collector’s hopper bag is easily emptied by pulling the cord from the driver’s seat. Do not secure the cord to the ride-on mower in such a way that it catches in the wheels or in other rotating parts. Do not drive too close to naked flames when using or emptying, as the hopper bag and the brushes can be damaged by heat or fire. Always empty the hopper bag after each use. Damp or wet grass and leaves can cause damage if stored for an extended period. MAINTENANCE The...
Page 8
NOTES .................................................................................................................................................................... ............................................................................................................................... ..................................... ............................................................................................................................... ........................................
Page 9
MOWING AHEAD GGP Sweden AB · Box 1006 · SE-573 28 TRANÅS www.stiga.com
