Stiga Lawn Mower Dino Instructions Manual

DEUTSCHD
DINO
8211-3389-05

SVENSKAS
MAX
MIN
MAX
MIN
12
34
7. Tecumseh8.
2.
4.
ADD
FULL
FULL
ADD
6. Briggs & Stratton
STOP
G
B
3.
5.
1.

SVENSKA S
0,75 mm
3x
3x
10. Tecumseh
14.
9. Briggs & Stratton
12. Briggs & Stratton
13. Tecumseh
15.
11 .
Briggs & Stratton : 0,76 mm
Tecumseh: 0,6 mm
A
D
C
E
40 Nm
1 2
3

ENGLISHGB
SYMBOLS
The following symbols are displayed on the ma-
chine in order to remind you about the safety pre-
cautions and attention necessary when using the
machine.
The symbols mean:
Warning! Read the Instruction Book and
Safety Manual before using the machine.
Warning! Keep spectators away. Beware
of objects being flung out.
Warning! Do not put hands or feet under
the cover of the machine when it is run-
ning.
Warning! Before starting any repair work,
remove the spark plug cable from the
spark...

ENGLISHGB
Briggs & Stratton:
Remove and dry the dipstick (fig. 6). Slide it down
completely and tighten it. Unscrew and pull it up
again. Read-off. If the oil level is low, fill with oil
up to the “FULL/MAX” mark.
Tecumseh:
Clean the area round the oil plug, then remove the
plug (fig. 7). If the oil is not level with the edge of
the hole, carefully pour in clean oil. Replace the oil
plug.
FILL UP THE PETROL TANK
Fill with petrol before starting the en-
gine. Never remove the filler cap or fill
with...

ENGLISHGB
CLEANING
After each time it is used the mower should be
cleaned. This is particularly important on the un-
derside of the mower casing. Wash out with the
garden hose. The mower will then last longer and
function better.
High pressure washing units should not be used. If
grass has dried on to the mower casing it can be re-
moved by scraping. If necessary, give the under-
side a touch of paint to prevent rusting.
Clean the silencer and the surrounding
area regularly to remove grass, dirt and...

ENGLISHGB
When replacing the blade, the blade bolt should
also be replaced.
The guarantee does not cover damage to the blade,
blade holder or engine caused by running into ob-
stacles.
When replacing the blade, the blade holder and
blade bolt, always use original spare parts. Non-
authentic spare parts could lead to the risk of per-
sonal injury or damage, even if they fit the ma-
chine.
SHARPENING OF THE BLADE
Sharpening of the blade must be done by wet meth-
od grinding, using a whetstone or a...
