Stiga Lawn Mower Multiclip Instructions Manual
Here you can view all the pages of manual Stiga Lawn Mower Multiclip Instructions Manual. The Stiga manuals for Lawn Mower are available online for free. You can easily download all the documents as PDF.
Page 1
DEUTSCHD Multiclip 8211-3417-04
Page 2
2 SVENSKA S 5. 6. 1. 2. 230 V 3. 4. 1 2 7.
Page 3
3 SVENSKAS 3 1 2 10. 9. 36 mm 19 mm 11 . 8.
Page 4
4 ENGLISHGB SYMBOLS The following symbols are displayed on the ma- chine in order to remind you about the safety pre- cautions and attention necessary when using the machine. The symbols mean: Warning! Read the Instruction Book and Safety Manual before using the machine. Warning! Keep spectators away. Beware of objects being flung out. Warning! Take out the safety key before any type of maintenance is carried out. Warning! Do not put hands or feet under the cover of the machine when it is running....
Page 5
5 ENGLISHGB CHARGING BEFORE WINTER STORAGE The battery should always be stored ful- ly charged. 1. Take the battery out of the mower. 2. Carefully wipe off the battery. 3. Store the battery outside of the mower in adry and coolplace. USING THE MOWER STARTING/STOPPING THE MOWER Keep hands and feet well away from the rotating blade(s). Never put your hand or foot under the blade casing or in the grass ejector unit while the motor is running. 1. Fix the battery in place in the mower (fig. 4).2. Insert the...
Page 6
6 ENGLISHGB MOWING TIPS For best cutting results and to ensure that the bat- tery lasts as long as possible, the following rules should be followed: Drive the mower at a slow and even pace Try to avoid excessive starting and stopping, as this draws a lot of current. Make sure that the motor is running at full speed at all times when mowing. Mow regularly and often, especially when the grass is growing quickly. Do not mow more than a third of the total height of the grass during one mowing...
Page 7
7 ENGLISHGB Problem Possible causes 1. Mower does not start when safety key is inserted and the safety han- dle is pressed inA. Check to make sure the safety key has been properly inserted and that the engine protection is pressed in. B. Remove safety key, turn mower over on side and check that blade is not obstructed. C. Is battery fully charged? Plug in charger and check lamps. 2. Mower stops while mowing (for reason other than releasing the safety handle).A. The engine protection in the safety key has...
