Stiga Lawn Mower Ready, Ready HST Instructions Manual

STIGA
READY
READY HST
8211-0335-01

SVENSKAS
8
7
9
1
23
45
1
2
34
56

SVENSKA
S
0,7 - 0,8 mm
67
89
1011
1213

ENGLISHGB
GENERAL
This symbol indicates WARNING. Per-
sonal injury and/or damage to property
may result if the instructions are not
followed carefully.
You must read these instructions for
use and the accompanying pamphlet
“SAFETY INSTRUCTIONS” careful-
ly, before starting up the machine.
SYMBOLS
The following symbols appear on the machine.
They are there to remind you of the care and atten-
tion required in use.
This is what the symbols mean:Warning!
Read the instruction manual and the safety...

ENGLISHGB
3. PARKING BRAKE
An inhibitor that can lock the brake pedal in the de-
pressed position. Depress the brake pedal fully. Raise the
inhibitor and then release the brake pedal.
The parking brake is released by pressing
the brake pedal. The spring-loaded inhibitor slides
to one side.
Make sure that the parking brake is released when
operating the machine.
4. DRIVE PEDAL (Ready HST)
A pedal that activates th e variable transmission.
1. Depress the pedal with the
ball of your foot – the...

ENGLISHGB
AREAS OF USE
The machine may only be used for the following
tasks using the genuine STIGA accessories stated.
Mowing:
With cutting deck 13-2940 (85M).
The maximum vertical load on the towing hitch
must not exceed 100 N.
The maximum over-run load on the towing hitch
from towed accessories must not exceed 500 N.
NOTE! Before using a trailer – contact your insur-
ance company.
NOTE! This machine is not intended to be driven
on public roads.
STARTING AND OPERATION
ENGINE CASING
To fill with...

ENGLISHGB
engine must stop (only Ready).
- press the drive pedal so that the machine starts  to move, release the drive pedal – the machine
should stop (only  Ready HST).
- engage the power take-off, lift your weight off
the seat – the engine should stop.
Do not use the machine if the safety sys-
tem is not working! Take the machine
to a service workshop for inspection!
STARTING ENGINE
1. Open the fuel cock (fig. 6).
2. Make sure that the spark plug cable is properly
in place.
3. Check to make...

ENGLISHGB
when the engine is not running.Prevent the machine from rolling by al-
ways applying the parking brake.
Prevent unintentional starting of the
motor by disengaging the drive, shut-
ting off the engine and disconnecting
the spark plug cable or removing the
starter key.
CLEANING
To reduce the risk of fire, keep the en-
gine, silencer, battery and fuel tank free
from grass, leaves and oil.
To reduce the risk of fire, regularly
check the machine for oil and/or fuel
leakage.
When washing the...

ENGLISHGB
Correct spark gap: 0.7 - 0.8 mm (fig. 10).
COOLING AIR INTAKE - ENGINE
The engine is air-cooled. A blocked cooling sys-
tem can damage the engine. The engine should be
cleaned at least once a year or every 100 hours of
operation.
Remove the fan casing. Cl ean the cooling fins on
the cylinder, the fan and the rotating protective
grille. Clean more frequently if mowing dry grass.
BATTERY
The battery is a valve-regulated battery with 12 V
nominal voltage. The battery is completely main-...

ENGLISHGB
PATENT - DESIGN
REGISTRATION
This machine or parts thereof is covered by the fol-
lowing patent and design registration:
9901091-0 (SE), 9901730-3 (SE)
00921248.1 (EPC), 00931809.8 (EPC)
GGP reserves the right to make alterations to the product
without prior notification.
