Page 1
DEUTSCHD Silent 33 8211-3413-04
Page 2
SVENSKA S 1. 4 4 ∅ 160 mm A BC 1 332 ∅ 130 mm A B C 12 1 3 2 4 3 = 40 mm 4 = 50 mm2 = 30 mm 1 = 20 mm 51 1 2 2 3 3 4 4 2. 55 6 7 1 3. 2 2
Page 3
SVENSKAS 8.9. 7. 230 V 4. ABC 5. 6. 36 mm 19 mm 10.11 .
Page 4
ENGLISHGB SYMBOLS The following symbols are displayed on the ma- chine in order to remind you about the safety pre- cautions and attention necessary when using the machine. The symbols mean: Warning! Read the Instruction Book and Safety Manual before using the machine. Warning! Keep spectators away. Beware of objects being flung out. Warning! Take out the safety key before any type of maintenance is carried out. Warning! Do not put hands or feet under the cover of the machine when it is running. Warning!...
Page 5
ENGLISHGB Always keep the mower battery away from wa- ter, sources of heat (ovens, radiators, open fires, etc.) and hazardous chemicals. Always use the accompanying genuine Stiga charger. Never use the charger for any other product. Never use the charger if it is damaged in any way. A damaged lead or charger should immediately be replaced at an authorised service workshop Take care of the leads. Never carry the charger by the lead. When charging is complete pull out the plug not the lead. If an...
Page 6
ENGLISHGB BYellow = the battery’s power has reduced. Be- tween 5% and 30% remains. CRed = 5% or less of the battery power remains. The machine will begin to beep and will switch itself off automatically. Stop mowing and re- charge the battery once it has cooled down (after about 30 minutes). Do not use the mower again until the battery is fully charged. Important:do not allow the battery power to com- pletely run down as this may damage the battery and shorten its operational life. MOWING TIPS For best...
Page 7
ENGLISHGB Problem Possible causes 1. Mower does not start when safety key is inserted and the safety han- dle is pressed inA. Check to make sure the safety key has been properly inserted and that the engine protection is pressed in. B. Remove safety key, turn mower over on side and check that blade is not obstructed. C. Is battery fully charged? Plug in charger and check lamps. 2. Mower stops while mowing (for reason other than releasing the safety handle).A. The engine protection in the safety key has...
