Stiga Lawn Tractor 8211 0003 80w Comfort Royal Prestige Operators Manual

61
ENGLISHEN
2.4.15 Engine casing (8:U)
In order to access the fuel cock, battery
and engine, the machine has an engine
casing that can be opened. The engine cas-
ing is locked with a rubber strap.
The engine casing is opened as follows:
1. Undo the rubber strap (8:V) at the front edge of
the casing.
2. Carefully lift the engine casing back.
Close in the reverse order.
The machine may not be operated un-
less the engine casing is closed and
locked. Risk of burns and crushing in-
juries....

62
ENGLISHEN
4 STARTING AND OPERATION
The machine may not be operated un-
less the engine casing is closed and
locked. Risk of burns and crushing in-
juries.
4.1 Filling with petrolAlways use lead-free petrol. You must never use 2-
stroke petrol mixed with oil.
The tank holds 12 litres. The level can easily be
read through the transparent tank.
NOTE! Ordinary lead-free petrol is a perishable
and must not be stored for more than 30 days.
Environmental petrol can be used, i.e. alkylate
petrol. This...

63
ENGLISHEN
4.5 Start1.  Open the fuel cock. See 14.
2.  Check that the spark plug cable(s) is/are in-
stalled on the spark plug(s).
3.  Check to make sure that the power take-off is
disengaged.
4.  Do not keep your foot on the drive pedal.
5. Comfort:
Starting cold engine – put the throttle control in
the choke position.
Starting warm engine – put the throttle control
at full throttle (approx. 2 cm behind the choke
position).
Royal, Prestige:
Put the throttle control at full throttle.
Starting...

64
ENGLISHEN
Servicing carried out at an authorised workshop
guarantees professional work using genuine spare
parts.
At each basic service and intermediate service car-
ried out at an authorised workshop, the service log
is stamped. A service log presenting these services
is a valuable document that improves the ma-
chine’s second-hand value.
5.2 PreparationAll service and all maintenance must be carried out
on a stationary machine with the engine switched
off.
Prevent the machine from rolling by...

65
ENGLISHEN
Type of oil: Synthetic oil 5W-50.
Oil quantity when changing: approximately 3.5 li-
tres.
5.6.1 Check – adjustment
1. Place the machine on a flat surface.
2. Read off the oil level in the reservoir. See fig.
18. The level should be level with the line.
3. If necessary, top up with more oil.
5.6.2 Draining
1. Run the machine at variable speeds for 10-20
minutes to heat up the transmission oil.
2. Position the machine completely horizontally.
3. Pull out both disengagement levers according...

66
ENGLISHEN
5.9 Battery
If acid comes into contact with the eyes
or skin, this can cause serious injuries.
If any part of the body has come into
contact with acid, rinse immediately
with copious amounts of water and seek
medical assistance as soon as possible.
The battery is a valve-regulated battery with 12 V
nominal voltage. The battery fluid does not need to
and cannot be checked or topped up. The only
maintenance that is required is charging, for exam-
ple after extended storage.
The battery...

67
ENGLISHEN
4.  Dismantle the filters. The pre-filter (25:C) is
placed over the air filter (25:D). Make sure that
no dirt gets into the carburettor. Clean the air fil-
ter housing.
5.  Wash the pre-filter (25:C) in liquid detergent
and water. Squeeze dry. Pour a little oil on the
filter and squeeze in the oil.
6. Assemble in the reverse order. Check that the
rubber seal (25:E) is undamaged. Replace the
seal if necessary.
5.10.3Air filter (Royal)
Clean the air filter every 3 months or after every...

68
FRANÇAISFR
1 GÉNÉRALITÉS
Ce symbole est un AVERTISSEMENT.
Risque de blessure ou de dégât matériel
en cas de non-respect des instructions.
Avant de démarrer la machine, lire at-
tentivement les instructions ainsi que
les consignes contenues dans le fascicule
« RÈGLES DE SÉCURITÉ » ci-joint.
1.1 SymbolesLes symboles suivants figurent sur la machine. Ils
attirent votre attention sur les dangers et les mesu-
res à respecter lors de l’utilisation et de la mainte-
nance.
Explication des symboles :...

69
FRANÇAISFR
2.4.2 Embrayage - frein de stationnement
(3:B)
Ne jamais enfoncer cette pédale pen-
dant les déplacements pour éviter toute
surchauffe des organes de transmission.
La pédale (3:B) se règle sur trois
positions :
•Relâchée. Lembrayage nest pas activé. Le
frein de stationnement nest pas activé.
• Enfoncée à moitié. La marche avant est désac-
tivée. Le frein de stationnement nest pas activé.
•Totalement enfoncé. La marche avant est dé-
sactivée. Le frein de stationnement est tout à
fait...

70
FRANÇAISFR
2.4.8 Réglage du choke (5:H)
(Royal, Prestige)
Commande servant au démarrage du moteur à
froid.
1. Manette tirée à fond – la soupape située
dans le carburateur est fermée. Pour le dé-
marrage à froid du moteur.
2. Commande enfoncée – volet de starter
ouvert. Pour le démarrage d’un moteur
chaud ou pendant l’utilisation de la machi-
ne.
Ne jamais conduire la machine avec le starter
tiré lorsque le moteur est chaud.
2.4.9 Démarreur/phare avant (4, 5:I)
La clé de contact permet de...
